STORZ POWER – LFP48100-5KWH
Follow these instructions for setting up Storz Power batteries and Sol-Ark inverters.
Be sure to consult the comprehensive technical documentation provided by Storz Power for specifications
and settings to ensure optimal performance and safety. Visit the manufacturer’s website and consult the
relevant documentation below.
Storz Power documentation
Make a custom cable as shown below or get it from Storz Power. Communications installation
and setup instructions are updated for newer battery models on the Storz Power website
Comm Installation and Setup Instructions
Custom RJ45 cable
Create two custom cables:
1. Custom cable #1: On one end of the RJ45 cable, cut all cables except for pins 4 (solid blue) and 5
(white-blue).
Custom cable #1: Battery-inverter communication connections
Wire color
Battery (RS485) port
Inverter port
Solid blue
4
2
White-blue
5
1
Solid green
6
6
2. Custom cable #2: On one end of the RJ45 cable, cut all cables except for pins 7 (white-brown) and 8
(solid brown).
Custom cable #2: Battery 1-battery 2 communication connections
Wire color
Battery 1 (RS485) port
Battery 2 (RS485) port
White-brown
7
7
Solid brown
8
8
The sides with custom pinouts will be connected to the Quick Link.
