Dyness – B4850 and Powerbox Pro
Follow these instructions for setting up Dyness batteries and Sol-Ark inverters.
Be sure to consult the comprehensive technical documentation provided by Dyness for specifications
and settings to ensure optimal performance and safety. Visit the manufacturer’s website and consult the
relevant documentation below.
Dyness documentation
Communications with this battery requires a custom cable (outdoor-rated models only)
B4850 Communications Installation and Setup Instructions
Custom RJ45 cable (outdoor-rated inverters only)
1. Create a custom RJ45 cable that connects battery port pins 4 (solid blue), 5 (white-blue), and 2 (solid
orange) to inverter port pins 4, 5, and 2 or 6, respectively.
Battery-inverter communication connections
Wire color
Battery (CAN-OUT) port
Inverter port
Solid blue
4
4
White-blue
5
5
Solid orange
2
2 or 6
Battery IDs and connections
1. Check the correct battery interconnection and connect to the inverter as specified in the Dyness user
manual.
2. Set the switch in position 3 on the DIP selection switches to the “ON” position for the battery
connected to the inverter.
