sol-ark 15K - RENON - Xtreme LV Series

Sol-Ark Battery Integration Guide | SK140-0026-005 31
RENON – Xtreme LV Series
Follow these instructions for setting up RENON batteries and Sol-Ark inverters.
Be sure to consult the comprehensive technical documentation provided by RENON POWER for
specifications and settings to ensure optimal performance and safety. Visit the manufacturer’s website
and consult the relevant documentation below.
RENON documentation
Communications Installation and Setup Instructions
Custom RJ45 cable
Create a custom RJ45 cable that connects battery port pins 6 (solid green), 7 (white-brown), and 8 (solid
brown) to inverter port pins 6, 4, and 5 respectively.
Battery-inverter communication connections
Wire color
Battery (INV1) port
Inverter port
Solid green
6
6
White-brown
7
4
Solid brown
8
5
Battery IDs and connections
1. Set the DIP switches for the “Inverter Dial Switch” on the master battery to the up position for switches
1 and 2.
2. Set the Address Dial Switch and Function Dial Switch on each stack per the manufacturer’s manual.
3. Connect all top modules (if in parallel) together using an RJ45 cable between Link A and Link B ports
(Link B on the master battery, Link A on the slave).
4. Power on the battery stack by pressing the Power button. If in parallel, turn on the slave units first, then
the master last.
You need a custom RJ45 cable for this setup.
