Deka Duration – DD5300 (Low Voltage configuration)
Follow these instructions for setting up Deka batteries and Sol-Ark inverters.
Be sure to consult the comprehensive technical documentation provided by Deka for specifications and
settings to ensure optimal performance and safety. Visit the manufacturer’s website and consult the
relevant documentation below.
Deka documentation
Communications with this battery requires a custom cable.
• Make sure that you are not wiring to the High Voltage connection terminals of the Deka-DD5300
battery.
• See the Installation & Operation (I&O) manual of the battery manufacturer and verify the proper
communications configuration of CANBus connections and dip switch settings.
Communications Installation and Setup Instructions
Custom RJ45 cable
1. Create a custom RJ45 cable that connects battery port pins 1 (white-orange), 2 (solid orange), and 3
(white-green) to inverter port pins 4, 5, and 2 (indoor-rated models) or 6 (outdoor-rated models),
respectively.
Battery-inverter communication connections
Wire color
Battery (CAN-A port
Inverter port
White-orange
1
4
Solid orange
2
5
White-green
3
2 (indoor only) or 6 (outdoor only)
