If not already ON - turn ON AC to the inverter by turning ON the circuit breaker
on the main distribution panel.
Open SetApp and follow the instructions on the screen (scan the inverter bar-
code; move the ON/OFF/P switch to P position (for less than 5 sec) and
release).
The mobile device creates a Wi-Fi connection with the inverter and displays the
main Commissioning screen.
In the main menus, tap the menu red arrows (›)to perform the system commissioning
or configuration task. Tap the Back arrow (‹) to return to the previous menu.
The next sections provide more information about configuration options (in addition to
Country and Language and Pairing, described in
Step 2: Commissioning and
Configuring the Installation
on page 43).
Setting Country and Language
1.
From the Commissioning screen select Country and Language .
2.
From the Country drop-down list, select the required country setting.
WARNING!
The inverter must be configured to the proper setting in order to ensure that
it complies with the country grid code and functions properly with the
country grids.
AVERTISSEMENT!
L'onduleur doit être configuré pour le pays approprié afin d'assurer un
fonctionnement convenable avec le réseau de ce pays.
3. From the Language drop-down list, select the language.
4. Tap Set Language.
Pairing
1.
From the main menu, select Pairing.
2. Tap Start Pairing.
3.
When Pairing Complete is displayed, the system startup process begins:
Since the inverter is ON, the power optimizers start producing power and the
inverter starts converting AC.
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
44 Step 2: Commissioning and Configuring the Installation
