Meter Interfaces
This section describes the SolarEdge inline meter's interfaces.
Figure 7: Inline Meter Interfaces
Main line connectors: inputs/output terminal blocks
RS485: detachable connector for wired connectivity with the inverter
Internal antenna: for wireless connectivity with the inverter
Three push buttons: to operate the inline meter display
LEDs: used to monitor meter status:
Orange: meter operation
Blue: Energy Net/RS485 communication status
Display: used to view energy readings and to configure the inline meter.
11
Inline Energy Meter with SolarEdge Energy Net Communications
