Back of the MaxWeb XPN, terminals at the top
Relay outputs
NC1
C1
N01
NC2
C2
N02
NC3
C3
N03
NC4
C4
N04
2
1
3
4
5
6
7
8
9
10
11
12
NC
C
NO
Fig. 69: Output connection diagram relay outputs
Back of the MaxWeb XPN, terminals at the bottom
Digital inputs
Alarm inputs
IN1 IN2 IN3 IN4 IN5 IN6 IN7 IN8
V+
GND IN_A IN_B
2
1
3
4
5
6
7
8
9
10
11
12
IN_A
IN_B
GND
Fig. 70: Input connection diagram alarm inputs
