● Status
The status function contains five items of the inverter(grid, solar, charger, eps and
Load).
Press up and down to select and press “OK” to confirm the selection, press “ESC”
to return to Menu.
a) Grid
This status shows the current grid condition such as voltage, current, output
power and the local consumed power.
Pout measures the output of the inverter;
Pgrid measures power export to or import from grid.
Positive value means the energy feeds into grid, negative value means the
energy used from the grid.
Grid
Solar
Charger
EPS
Status
Ø
Status
Grid
Solar
Battery
Status
U 000.0V
I 00.0A
P 00.0W
Grid
b) Solar
This status shows the real time PV condition of the system, such as input
voltage, current and power situation of each PV input.
U1 360.0V
I1 1.0A
P1 360W
Solar
50
51
Setting Setting
C) Charger
This status shows the charger situation of the system. Include the battery
voltage, charge or discharge current. Charge or discharge power, battery
capacity and battery temperature. “+” means in charging; “-” means in
discharging.
U 100.0V
I +1.0A
P +100W
Charger
d) EPS
EPS will only have data when the inverter is working in EPS mode, it will show the
real time data of the EPS output such as voltage, current, power, frequency.
EPS
U 220V
I 12A
P 2640VA
To Next Page
