EN - GDK installation and operating guide - SOMFY
Product presentation
> Kit contents
Q
C
M
N
O
Ra
N
E
K
F
L
B
A
J
I
G
P
H
D
Ra
Ra
Ra
Ra1
Ra1
Ra2
Ra2
P
O
Mark Designation Qty
A
Motor head x 1
B Flap x 1
C Lintel bracket x 1
D Door bracket x 1
E Ceiling mounting bracket x 2
F Motor head mounting bracket x 2
G Manual back release device x 1
H Connecting arm x 1
I End limit stop x 1
J TCB-H 4.2x13 zn self-tapping screws x 2
K Power supply cord x 1
Mark Designation Qty
L
TH10 M8x12 zn washer screws x 4
M TH M8x16 zn screws x2
N HU8 nut x 6
O Shaft x 2
L Circlips x 2
Q Thread-forming screws Ø 4x8
(motor head) x 4
Ra 3-part rail x 1
Ra1 Sleeve x 2
Ra2 Thread-forming screws Ø 4x8
(sleeves) 2 x 4
