EN - GDK installation and operating guide - SOMFY
Installation
ªïªÚ¦ÀÚ·áÚÿ½ªáÚĩ·ĄòÿÀáÚȘÀÿÙė
be necessary to cut the link arm.
During this operation, check that there is no risk that the back release device cable will subsequently become snagged
on an element protruding from the car (for example a roof rack).
1 2
I
J
• Release the carriage using the manual back release device
and move the door to the open position.
Do not open the door fully, but position it so that it does
not reach its stops.
• Position the stop against the carriage.
• Mark the mounting holes.
• Drill the holes with a
ǦɃÙÙ¦òÀÓÓÀÿȗ
• Fix the stop using the self-tapping screws
J
.
1 2
n½ªöªÿÀáÚá¶ÿ½ªÓÀÚÐòÙĩĖª¦ÿáÿ½ª
door bracket must be as horizontal as
possible.
1.4 Settings
• If necessary, adjust the belt tension.
n½ª ÿªÚöÀáÚ òĄªò ÙĄöÿ ÚªĐªò ª ¶ĄÓÓė áÙïòªööª¦ș ÿá
obtain the correct tension, the rubber should measure
between 18 and 20 mm (see page 10).
> Checking the tension of the belt
> Fastening the link arm to the door and the carriage (continued)
> Adjusting and fastening the opening stop
1
EN
