MIC-10 ● MIC-30 – USER MANUAL
CONTENTS
1 Safety ................................................................................................................ 4
2 Meter configuration ......................................................................................... 5
3 Measurements .................................................................................................. 6
3.1 Measurement of insulation resistance ...................................................................... 6
3.1.1 Double-lead measurement (with a shielded lead) .............................................................. 6
3.1.2 Three-lead measurement (with a shielded lead) .............................................................. 10
3.1.3 Measurements with WS-04 adapter ................................................................ 10
3.2 Low-voltage measurement of resistance ................................................................ 12
3.2.1 Measurement of resistance of protective conductors and equipotential bonding with
200 mA current ............................................................................................................... 12
3.2.2 Measurement of resistance ............................................................................................. 14
3.2.3 Compensation of test leads resistance ............................................................................ 15
3.3 Voltage measurement ............................................................................................ 16
3.4 Remembering the last measurement result............................................................ 16
4 Memory of measurement result data ............................................. 17
4.1 Storing the measurement results in the memory .................................................... 17
4.2 Viewing memory data ............................................................................................. 19
4.3 Deleting memory data ............................................................................................ 20
4.3.1 Deleting bank data .......................................................................................................... 20
4.3.2 Deleting the whole memory ............................................................................................. 21
5 Wireless data transmission ............................................................ 22
5.1 Computer connection accessories ......................................................................... 22
5.2 Data transmission with Bluetooth 4.2 module ........................................................ 23
5.3 Data transmission with OR-1 radio module ............................................................ 24
6 Firmware update .............................................................................. 25
7 Power supply of the meter ............................................................................ 26
7.1 Monitoring of the power supply voltage .................................................................. 26
7.2 Replacing battery/rechargeable batteries ............................................................... 26
7.3 General principles regarding using NiMH rechargeable batteries .......................... 27
8 Cleaning and maintenance ........................................................................... 27
9 Storage ............................................................................................................ 28
10 Dismantling and disposal ............................................................................. 28
11 Technical specifications ............................................................................... 28
11.1 Basic data .............................................................................................................. 28
11.2 Other technical specification .................................................................................. 31
11.3 Additional data ....................................................................................................... 31
11.3.1 Additional uncertainties according to IEC 61557-2 (R
ISO
) ................................................. 31
11.3.2 Additional uncertainties according to IEC 61557-4 (R
CONT
200mA) .................................. 32
12 Accessories .................................................................................................... 32
12.1 Standard accessories ............................................................................................. 32
12.2 Optional accessories .............................................................................................. 33
13 Manufacturer .................................................................................................. 34
