System Overview
This ultrasound system adopts advanced ultrasonic Doppler technologies.
To ensure the performance and availability of this ultrasound system, you should be thoroughly familiar with the
operations of system components, the control panel, the key panel and the basic screen.
2.1 System Conguration
The standard system conguration mainly consists of the following items:
●
Main unit
●
Probes
●
Others: See the Packing List in the packaging box.
2.2 Physical Specications
●
System dimensions: approx. 726mm(W)×1389mm(H)×559mm(D)
●
System weight: approx. 60kg
2.2.1 System Components
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Figure 2-1 System Overview
