4 Customizing Your System
Basic User Manual 45
Item Description
Service List Select the DICOM worklist server.
●
Select Append from the drop-down list beside Service List, input the relevant
parameters information and click Add to add a new server.
●
Select any server from the drop-down list and click Delete to delete the server.
Remote Host Name Enter the name of the DICOM worklist server.
IP Address Set the IP address of the DICOM worklist server.
After the setting, click Ping to test the connection.
DICOM AE Title Set the Application Entity (AE) title of the DICOM worklist server.
Port Number Set the port number of the DICOM worklist server.
Connect Timeout(sec) Set the time limit for the network connection timeout.
Repeat Count Set the number of repeated attempts for connecting to the DICOM worklist server.
Dimse Timeout(sec) Set the timeout time for sending the Dimse command.
Acse Timeout(sec) Set the timeout time for sending the Acse command.
Max. Result Set the maximum number of patient records that can be sent to the system.
Click Echo to verify the connection between the system and the server after you input the settings. A summary
displays if the connection is veried.
4.8.4 MPPS (Modality Performed Procedure Step) Settings
You can connect the system to the MPPS server and adjust the relevant settings on the MPPS tab.
System Setting
Store C-Store Worklist
Print QR ListMPPS
Peripheral
General
Comment
Measure
DICOM
Load Default
User Security
About
Save&Exit
Exit
Bodymark
Delete
Add
Service List
MPPS
DICOM MPPS
MPPS
Remote HostName
Port Number
109
Connect Timeout(sec)
10
Repeat Count
2
Dimse Timeout (sec)
10
Acse Timeout (sec)
30
Ping
Echo
IP Address
192.168.254.104
DICOM AE Title
AE
Report
Touch Screen
Figure 4-19 DICOM Settings Menu - MPPS Tab
