Show Menu Of
Setup | Show Menu Of
Changes the menu between Main image and PIP if the PIP mode is on.
Input Search
Setup | Input Search
Toggles input search on/off.
Advanced
Setup | Advanced
This menu can be used to adjust various engineering setups.
> Remote Protocol
Setup | Advanced | Remote Protocol
This function can be used to select the remote protocol.
> Slave Address
Setup | Advanced | Slave Address
This function can be used to set a slave address for the remote protocol.
> Ext. Source Select
Setup | Advanced | Ext. Source Select
This function can be used to witch the external source select On/ Off.
> DDC Supported Inputs
Setup | Advanced | DDC Supported Inputs
This function can be used to select the handling of input sources.
The following parameters can be selected:
DDC / CI input source is always the active main source
DDC / CI is always connected to the DVI 1 input
DDC / CI is always connected to the DVI 1 input
Table 8: “DDC Supported Inputs” configuration options
> Backlight Control
Setup | Advanced | Backlight Control
This function can be used to change the settings of backlight control.
The following configuration options are possible:
If the video signal source (Input) is set internal or external to DP-1 the backlight control
follows the DDC / CI commands. If DP-2 is selected, key inputs are the valid controls for
backlight.
The selected brightness control (Input) source is driving the backlight regardless which
video signal source is selected. In the separate backlight mode, the settings of the
brightness are memorized for each input. When switching between the sources the
brightness will reappear as the setting was before switched to the other input.
Table 9: “Backlight Control” configuration options
> Status LEDs
Setup | Advanced | Status LEDs
This function can be used to switch the LEDs On/ Off.
