Table 10: “Dimming Mode” configuration options
> COM Port Settings
Setup | Advanced | COM Port Settings
This function can be used to configure the properties of the controller board
>> COM Interface
Setup | Advanced | COM Port Settings | COM Interface
This function can be used to set the COM port (RS-232, RS-485 Full Duplex or RS-485 Half
Duplex).
>> Baud Rate
Setup | Advanced | COM Port Settings | Baud Rate
This function can be used to select the baud rate (2400, 4800, 9600, 14.4k, 19.2k, 28.8k,
38.4k, 57.6k, 76.8k, 115.2k).
>> Data Bits
Setup | Advanced | COM Port Settings | Data Bits
This function can be used to set the number of data bits (7, 8).
>> Stop Bits
Setup | Advanced | COM Port Settings | Stop Bits
This function can be used to set the number of stop bits (1, 2).
>> Parity
Setup | Advanced | COM Port Settings | Parity
This function can be used to set the kind of parity (None, Odd, Even)
Display On Counter
Setup | Display On Counter
This counter shows how many hours the display has been switched on. If, for example, no valid input signal is
found the display is switched off automatically - during this time this timer is not increased.
Power On Counter
Setup | Power On Counter
This counter shows how many hours the board has been switched on. This counter increases as long as the
board is powered and not switched to full power off mode by pressing the power key on the IR remote control
or on the OSD keypad. This counter also increases when no valid input signal is found, and the board is in sleep
mode.
Main Input
Setup | Main Input
Shows the detected input mode (resolution and frame rate) of the main input channel.
