Working Instruction, Mechanical
3/000 21-1/FEA 209 544/129 A
Company Internal
©
Sony Ericsson Mobile Communications AB
28(34)
4 Reassembly
After replacing a part being listed in Replacements, the instruction of that section usually ends by
directing you to this Reassembly section with a specification of the instructions you have to carry out
in order to reassemble the phone.
4.1 Overview
The reassembly is done in the following sequence:
1. Display
2. Navi key PBA
3. Front Cover Assembly
4. Main PCB
5. Rear Back Cover
6. Battery, Battery Cover and M2
Start
Done
