Working Instruction, Mechanical
3/000 21-1/FEA 209 544/129 A
Company Internal
©
Sony Ericsson Mobile Communications AB
32(34)
Rear Back Cover continued
Insert and tighten the three screws.
1, 2 – Torx T6 14Ncm
3 – JCIS 10Ncm
Insert the two screw Caps.
Insert and tighten the two screws (Torx T6 14Ncm).
Position and put the Panel Antenna in place.
