6-2
BDP-BX2/S360
Pin No. Name I/O Description
B25 GPIO40 I/O VODY3: Digital Video Y Data Output
B26 GPIO42 I/O VODY5: Digital Video Y Data Output
B27 GPIO45 I/O VODY8: Digital Video Y Data Output
B28 GPIO46 I/O VODY9: Digital Video Y Data Output
B29 N.U. I/O Not used
B30 N.U. I Not used (Fixed at "H")
B31 N.U. O Not used
B32 N.U. I Not used (Fixed at "H")
B33 S2CSB I Clocked Serial I/F 2 Slave Select Input
B34 VOID - This pin is not ball.
B35 VOID - This pin is not ball.
C1 VOID - This pin is not ball.
C2 SDRV2 O Motor Drive I/F Thread Drive Output
C3 AVDD33 - Analog 3.3V supply for Drive Controller Block
C4 FPDVINP2 I RF I/F Front Monitor Input (+)
C5 FPDVINP I RF I/F Front Monitor Input (+)
C6 AGND - Analog GND for Drive Controller Block
C7 AGND - Analog GND for Drive Controller Block
C8 AVDD15 - Analog 1.5V supply for Drive Controller Block
C9 AVDD33 - Analog 3.3V supply for Drive Controller Block
C10 AVDD15 - Analog 1.5V supply for Drive Controller Block
C11 AGND - Analog GND for Drive Controller Block
C12 VDD15RVAD - Power Supply 1.5V for RV ADC
C13 AVDD15 - Analog 1.5V supply for Drive Controller Block
C14 AGND - Analog GND for Drive Controller Block
C15 MON3/RFP6 I/O RF I/F Internal Signal Monitor, Monitor Input Signal/GPIO 6
C16 MA4 O External SDRAM I/F Memory Address Output
C17 DVDD33 - Digital 3.3V supply for Drive Controller Block)
C18 DGND - Digital GND for Drive Controller Block
C19 SAGNDDIG - Digital ground for Serial ATA
C20 SAGNDDIG - Digital ground for Serial ATA
C21 SAGNDDIG - Digital ground for Serial ATA
C22 SAGNDDIG - Digital ground for Serial ATA
C23 SAGNDDIG - Digital ground for Serial ATA
C24 GPIO41 I/O VODY4: Digital Video Y Data Output
C25 GPIO50 I/O VODC3: Digital Video Cb/Cr Data Output
C26 GPIO51 I/O VODC4: Digital Video Cb/Cr Data Output
C27 VDD3 - 3.3V supply (I/O buffers)
C28 GND - Ground for digital and DDR2 SDRAM
C29 VDD3 - 3.3V supply (I/O buffers)
C30 ATX O Sample data output for S/PDIF, HDMI
C31 VDD3 - 3.3V supply (I/O buffers)
C32 S2CKIN I Clocked Serial I/F 2 Serial Clock Input
C33 S2DOUT O Clocked Serial I/F 2 Serial Data Output
C34 S2DIN I Clocked Serial I/F 2 Serial Data Input
C35 VOID - This pin is not ball.
D1 MDRV O Motor Drive I/F Spindle Drive Output
D2 SDRV1 O Motor Drive I/F Thread Drive Output
D3 DAOUT2 O RF I/F General-purpose D/A Converter Output
D4 FPDVINN2 I RF I/F Front Monitor Input (-)
D5 FPDVINN I RF I/F Front Monitor Input (-)
D6 CBC I/O RF I/F Connector to condenser for setting WOBBLE circuit (A+D) signal AGC response speed
D7 RFTSTIN2 I RF I/F RF Test Input
D8 REF16 O RF I/F System Reference Voltage Output (for 3.3V supply)
D9 RFOP O RF I/F Read RF Output (+)
D10 RFTST3/RFP3 O RF I/F RF Test/GPIO 3
D11 DGND - Digital GND for Drive Controller Block
D12 PB0/SW1 I/O General Port I/F, Three values Control Output SW (default)
D13 PB1/SW2 I/O General Port I/F, Three values Control Output SW (default)
D14 MA1 O External SDRAM I/F Memory Address Output
D15 MA6 O External SDRAM I/F Memory Address Output
