6-3
BDP-BX2/S360
Pin No. Name I/O Description
D16 MA0 O External SDRAM I/F Memory Address Output
D17 MA2 O External SDRAM I/F Memory Address Output
D18 MA3 O External SDRAM I/F Memory Address Output
D19 GND - Ground for digital and DDR2 SDRAM
D20 SAVDDDIG - 1.05V supply
D21 SAVDDTIO - 1.8V supply (Serial ATA Tx I/O)
D22 GPIO34 I/O Video Pixel Clock
D23 GPIO37 I/O VODY0: Digital Video Y Data Output
D24 GPIO49 I/O VODC2: Digital Video Cb/Cr Data Output
D25 GPIO53 I/O VODC6: Digital Video Cb/Cr Data Output
D26 GND - Ground for digital and DDR2 SDRAM
D27 AO0BD3 O Audio PCM Serial Data Output
D28 AO0BD0 O Audio PCM Serial Data-L/R Output/Down Mixed Output
D29 GND - Ground for digital and DDR2 SDRAM
D30 AO0MCK O Audio Master Clock Output
D31 GND - Ground for digital and DDR2 SDRAM
D32 N.U. I Not used
D33 S0DIN I Not used
D34 S0DOUT O Clocked Serial I/F 0 Serial Data Output
D35 S0CKOUT O Clocked Serial I/F 0 Serial Clock Output
E1 FDRV O Motor Drive I/F Focus Drive Output
E2 DAOUT0 O RF I/F General-purpose D/A Converter Output
E3 DAOUT1 O RF I/F General-purpose D/A Converter Output
E4 VDD15WBLAD - Power Supply 1.5V for WOBBLE ADC
E5 GND_WBLAD - Ground for WOBBLE ADC
E6 CWAGC I/O RF I/F Connection to condenser for setting WOBBLE circuit AGC response speed
E7 CAD I/O RF I/F Connection to condenser for setting WOBBLE circuit (A+D) signal AGC response speed
E8 REF075 O RF I/F System Reference Voltage Output (for 1.5V supply)
E9 RFON O RF I/F Read RF Output (-)
E10 AGCINP I RF I/F AGC Input (+)
E11 DVDD33 - Digital 3.3V supply for Drive Controller Block)
E12 PB3/SW4 I/O General Port I/F, Three values Control Output SW (default)
E13 PB2/SW3 I/O General Port I/F, Three values Control Output SW (default)
E14 MA7 O External SDRAM I/F Memory Address Output
E15 MA10 O External SDRAM I/F Memory Address Output
E16 MA8 O External SDRAM I/F Memory Address Output
E17 MA5 O External SDRAM I/F Memory Address Output
E18 GPIO7 O GPIO7
E19 N.U. I/O Not used
E20 SAVDDDIG - 1.05V supply
E21 SAVDDTIO - 1.8V supply (Serial ATA Tx I/O)
E22 GPIO38 I/O VODY1: Digital Video Y Data Output
E23 GPIO47 I/O VODC0: Digital Video Cb/Cr Data Output
E24 GPIO54 I/O VODC7: Digital Video Cb/Cr Data Output
E25 GND - Ground for digital and DDR2 SDRAM
E26 AO0BD1 O Audio PCM Serial Data-SL/SR Output
E27 AO0LRCK O Audio L/R Clock Output
E28 AO1BD O Audio PCM Serial Data-L/R Output/Down Mixed Output
E29 AO1BCK O Audio Data Clock Output
E30 GPIO10 I/O FORMAT0 (480, 1080="0" 720="1")
E31 N.U. I/O Not used
E32 GND - Ground for digital and DDR2 SDRAM
E33 GND - Ground for digital and DDR2 SDRAM
E34 VDD3 - 3.3V supply (I/O buffers)
E35 GND - Ground for digital and DDR2 SDRAM
F1 TDRV O Motor Drive I/F Tracking Drive Output
F2 AVDD15 - Analog 1.5V supply for Drive Controller Block
F3 AVDD15 - Analog 1.5V supply for Drive Controller Block
F4 AGND - Analog GND for Drive Controller Block
F5 AGND - Analog GND for Drive Controller Block
F6 AVDD33 - Analog 3.3V supply for Drive Controller Block
