6-16
BDP-BX2/S360
Pin No. Name I/O Description
AG3 D0ADD2 O DDR2 Address Output
AG4 D0CS0B O DDR2 Chip Select
AG5 D0RASB O DDR2 Raw Address Strobe Signal
AG6 D0DQ22 I/O DDR2 Data Input/Output
AG7 D0ADD15 O DDR2 Address Output
AG8 GND - Ground for digital and DDR2 SDRAM
AG9 VDD18 - 1.8V supply (DDR2 SDRAM)
AG10 GND - Ground for digital and DDR2 SDRAM
AG11 VDD18 - 1.8V supply (DDR2 SDRAM)
AG12 GND - Ground for digital and DDR2 SDRAM
AG13 D1VDD10 - 1.05V supply (DDR2 SDRAM DLL)
AG14 VDD18 - 1.8V supply (DDR2 SDRAM)
AG15 D1VDD10 - 1.05V supply (DDR2 SDRAM DLL)
AG16 GND - Ground for digital and DDR2 SDRAM
AG17 D1VREF I DDR2 Reference Voltage
AG18 GND - Ground for digital and DDR2 SDRAM
AG19 D1VDD10 - 1.05V supply (DDR2 SDRAM DLL)
AG20 VDD18 - 1.8V supply (DDR2 SDRAM)
AG21 D1VDD10 - 1.05V supply (DDR2 SDRAM DLL)
AG22 GND - Ground for digital and DDR2 SDRAM
AG23 VDD3 - 3.3V supply (I/O buffers)
AG24 GND - Ground for digital and DDR2 SDRAM
AG25 VDD10 - 1.05V supply (core)
AG26 GND - Ground for digital and DDR2 SDRAM
AG27 GND - Ground for digital and DDR2 SDRAM
AG28 N.U. I Fixed at "H"
AG29 RDATA5/GDATA5 I/O ROM Data Input/Output
AG30 RDATA4/GDATA4 I/O ROM Data Input/Output
AG31 VDD3 - 3.3V supply (I/O buffers)
AG32 RDATA3/GDATA3 I/O ROM Data Input/Output
AG33 RDATA2/GDATA2 I/O ROM Data Input/Output
AG34 RDATA1/GDATA1 I/O ROM Data Input/Output
AG35 GND - Ground for digital and DDR2 SDRAM
AH1 D0DQS2 I/O DDR2 Positive Data Strobe
AH2 D0DQS2B I/O DDR2 Negative Data Strobe
AH3 GND - Ground for digital and DDR2 SDRAM
AH4 D0DQ21 I/O DDR2 Data Input/Output
AH5 D0DQ23 I/O DDR2 Data Input/Output
AH6 D0DQ20 I/O DDR2 Data Input/Output
AH7 GND - Ground for digital and DDR2 SDRAM
AH8 VDD18 - 1.8V supply (DDR2 SDRAM)
AH9 GND - Ground for digital and DDR2 SDRAM
AH10 VDD18 - 1.8V supply (DDR2 SDRAM)
AH11 GND - Ground for digital and DDR2 SDRAM
AH12 VDD18 - 1.8V supply (DDR2 SDRAM)
AH13 VDD18 - 1.8V supply (DDR2 SDRAM)
AH14 VDD18 - 1.8V supply (DDR2 SDRAM)
AH15 GND - Ground for digital and DDR2 SDRAM
AH16 GND - Ground for digital and DDR2 SDRAM
AH17 GND - Ground for digital and DDR2 SDRAM
AH18 GND - Ground for digital and DDR2 SDRAM
AH19 VDD18 - 1.8V supply (DDR2 SDRAM)
AH20 VDD18 - 1.8V supply (DDR2 SDRAM)
AH21 GND - Ground for digital and DDR2 SDRAM
AH22 GND - Ground for digital and DDR2 SDRAM
AH23 VDD3 - 3.3V supply (I/O buffers)
AH24 GND - Ground for digital and DDR2 SDRAM
AH25 VDD10 - 1.05V supply (core)
AH26 GPIO24 O NAND_WP (L: Write Protect)
AH27 GPIO26 O XAMUTE (L: MUTE)
AH28 GND - Ground for digital and DDR2 SDRAM
