BDP-BX2/S360
Pin No. Name I/O Description
AH29 RDATA0/GDATA0 I/O ROM Data Input/Output
AH30 RADD25/GADD25 O ROM Address Output
AH31 RADD24/GADD24 O ROM Address Output
AH32 GND - Ground for digital and DDR2 SDRAM
AH33 RADD23/GADD23 O ROM Address Output
AH34 RADD22/GADD22 O ROM Address Output
AH35 RADD21/GADD21 O ROM Address Output
AJ1 GND - Ground for digital and DDR2 SDRAM
AJ2 GND - Ground for digital and DDR2 SDRAM
AJ3 D0DQ18 I/O DDR2 Data Input/Output
AJ4 D0DQ16 I/O DDR2 Data Input/Output
AJ5 D0DQ30 I/O DDR2 Data Input/Output
AJ6 D0DQ19 I/O DDR2 Data Input/Output
AJ7 VDD18 - 1.8V supply (DDR2 SDRAM)
AJ8 GND - Ground for digital and DDR2 SDRAM
AJ9 VDD18 - 1.8V supply (DDR2 SDRAM)
AJ10 GND - Ground for digital and DDR2 SDRAM
AJ11 VDD18 - 1.8V supply (DDR2 SDRAM)
AJ12 GND - Ground for digital and DDR2 SDRAM
AJ13 VDD18 - 1.8V supply (DDR2 SDRAM)
AJ14 GND - Ground for digital and DDR2 SDRAM
AJ15 D1RQ1 O DDR2 Pull up (150 ohm) to DDR2 SDRAM power supply
AJ16 D1RQ0 O DDR2 Pull down (150 ohm) to DDR2 SDRAM GND
AJ17 GND - Ground for digital and DDR2 SDRAM
AJ18 VDD18 - 1.8V supply (DDR2 SDRAM)
AJ19 GND - Ground for digital and DDR2 SDRAM
AJ20 GND - Ground for digital and DDR2 SDRAM
AJ21 VDD18 - 1.8V supply (DDR2 SDRAM)
AJ22 VDD18 - 1.8V supply (DDR2 SDRAM)
AJ23 GND - Ground for digital and DDR2 SDRAM
AJ24 GND - Ground for digital and DDR2 SDRAM
AJ25 VDD3 - 3.3V supply (I/O buffers)
AJ26 GPIO25 O IT_REQ (Communication request for front micon)
AJ27 GPIO28 O EMMA_CSI0_DAC2_XCS (L: Active)
AJ28 GPIO23 O GLB_XRST (L: RESET)
AJ29 RADD20/GADD20 O ROM Address Output
AJ30 RADD19/GADD19 O ROM Address Output
AJ31 RADD18/GADD18 O ROM Address Output
AJ32 RADD17/GADD17 O ROM Address Output
AJ33 RADD16/GADD16 O ROM Address Output
AJ34 RADD15/GADD15 O ROM Address Output
AJ35 VDD3 - 3.3V supply (I/O buffers)
AK1 D0CLK1B O DDR2 Negative Clock
AK2 D0CLK1 O DDR2 Positive Clock
AK3 GND - Ground for digital and DDR2 SDRAM
AK4 D0DM2 I/O DDR2 Data Mask
AK5 D0DQ28 I/O DDR2 Data Input/Output
AK6 D0DQ17 I/O DDR2 Data Input/Output
AK7 GND - Ground for digital and DDR2 SDRAM
AK8 VDD18 - 1.8V supply (DDR2 SDRAM)
AK9 GND - Ground for digital and DDR2 SDRAM
AK10 D1DQ24 I/O DDR2 Data Input/Output
AK11 D1DQ25 I/O DDR2 Data Input/Output
AK12 GND - Ground for digital and DDR2 SDRAM
AK13 VDD18 - 1.8V supply (DDR2 SDRAM)
AK14 VDD18 - 1.8V supply (DDR2 SDRAM)
AK15 GND - Ground for digital and DDR2 SDRAM
AK16 GND - Ground for digital and DDR2 SDRAM
AK17 VDD18 - 1.8V supply (DDR2 SDRAM)
AK18 D1ADD9 O DDR2 Address Output
AK19 D1ADD1 O DDR2 Address Output
