BDP-BX2/S360
Pin No. Name I/O Description
AM11 D1DQ22 I/O DDR2 Data Input/Output
AM12 VDD18 - 1.8V supply (DDR2 SDRAM)
AM13 D1DM2 I/O DDR2 Data Mask
AM14 D1DQ23 I/O DDR2 Data Input/Output
AM15 D1CS1B O DDR2 Chip Select/Bank Address
AM16 D1ADD14 O DDR2 Address Output
AM17 D1ADD12 O DDR2 Address Output
AM18 GND - Ground for digital and DDR2 SDRAM
AM19 D1CKE O DDR2 Clock Enable
AM20 D1DM0 I/O DDR2 Data Mask
AM21 D1DQ3 I/O DDR2 Data Input/Output
AM22 D1DQ2 I/O DDR2 Data Input/Output
AM23 VDD18 - 1.8V supply (DDR2 SDRAM)
AM24 D1DQ8 I/O DDR2 Data Input/Output
AM25 D1DQ13 I/O DDR2 Data Input/Output
AM26 D1DM1 I/O DDR2 Data Mask
AM27 GND - Ground for digital and DDR2 SDRAM
AM28 FCSB0 O ROM Chip select
AM29 FCSB1 O ROM Chip select
AM30 FCSB2 O ROM Chip select (Not used)
AM31 FCSB3 O ROM Chip select (Not used)
AM32 GND - Ground for digital and DDR2 SDRAM
AM33 RADD3/GADD3 O ROM Address Output
AM34 RADD2/GADD2 O ROM Address Output
AM35 RADD1/GADD1 O ROM Address Output
AN1 VOID - This pin is not ball.
AN2 GND - Ground for digital and DDR2 SDRAM
AN3 D0DQ27 I/O DDR2 Data Input/Output
AN4 GND - Ground for digital and DDR2 SDRAM
AN5 VDD18 - 1.8V supply (DDR2 SDRAM)
AN6 GND - Ground for digital and DDR2 SDRAM
AN7 D1DQ30 I/O DDR2 Data Input/Output
AN8 GND - Ground for digital and DDR2 SDRAM
AN9 D1DQ29 I/O DDR2 Data Input/Output
AN10 D1DQ17 I/O DDR2 Data Input/Output
AN11 VDD18 - 1.8V supply (DDR2 SDRAM)
AN12 GND - Ground for digital and DDR2 SDRAM
AN13 D1ADD15 O DDR2 Address Output
AN14 D1ADD2 O DDR2 Address Output
AN15 D1ADD0 O DDR2 Address Output
AN16 D1ADD7 O DDR2 Address Output
AN17 D1ADD13 O DDR2 Address Output
AN18 D1CKERSTB I DDR2 D0CKERSTB output control
AN19 GND - Ground for digital and DDR2 SDRAM
AN20 D1DQ6 I/O DDR2 Data Input/Output
AN21 D1DQ4 I/O DDR2 Data Input/Output
AN22 VDD18 - 1.8V supply (DDR2 SDRAM)
AN23 GND - Ground for digital and DDR2 SDRAM
AN24 D1DQ12 I/O DDR2 Data Input/Output
AN25 GND - Ground for digital and DDR2 SDRAM
AN26 D1DQ15 I/O DDR2 Data Input/Output
AN27 GND - Ground for digital and DDR2 SDRAM
AN28 VDD18 - 1.8V supply (DDR2 SDRAM)
AN29 VDD3 - 3.3V supply (I/O buffers)
AN30 GRDYB I GIO I/F Ready for external device Not used)
AN31 FOEB/GOEB O NOR Flash ROM Output Enable
AN32 FWEB/GWEB O NOR Flash ROM Write Enable
AN33 VDD3 - 3.3V supply (I/O buffers)
AN34 RADD0/GADD0 O ROM Address Output
AN35 VOID - This pin is not ball.
