6-20
BDP-BX2/S360
Pin No. Name I/O Description
AP2 VOID - This pin is not ball.
AP3 GND - Ground for digital and DDR2 SDRAM
AP4 D1DQS3B I/O DDR2 Negative Data Strobe
AP5 GND - Ground for digital and DDR2 SDRAM
AP6 D1CLK1 O DDR2 Positive Clock
AP7 GND - Ground for digital and DDR2 SDRAM
AP8 D1DQS2B I/O DDR2 Negative Data Strobe
AP9 GND - Ground for digital and DDR2 SDRAM
AP10 VDD18 - 1.8V supply (DDR2 SDRAM)
AP11 GND - Ground for digital and DDR2 SDRAM
AP12 D1RASB O DDR2 Raw Address Strobe Signal
AP13 D1CS0B O DDR2 Chip Select
AP14 D1CASB O DDR2 Colmun Address Strobe Signal
AP15 GND - Ground for digital and DDR2 SDRAM
AP16 VDD18 - 1.8V supply (DDR2 SDRAM)
AP17 D1ADD8 O DDR2 Address Output
AP18 D1ADD10 O DDR2 Address Output
AP19 D1ADD3 O DDR2 Address Output
AP20 GND - Ground for digital and DDR2 SDRAM
AP21 VDD18 - 1.8V supply (DDR2 SDRAM)
AP22 GND - Ground for digital and DDR2 SDRAM
AP23 D1DQS0B I/O DDR2 Negative Data Strobe
AP24 GND - Ground for digital and DDR2 SDRAM
AP25 D1CLK0 O DDR2 Positive Clock
AP26 GND - Ground for digital and DDR2 SDRAM
AP27 D1DQS1B I/O DDR2 Negative Data Strobe
AP28 GND - Ground for digital and DDR2 SDRAM
AP29 VDD18 - 1.8V supply (DDR2 SDRAM)
AP30 NRBB I NAND Flash ROM Ready/Busy
AP31 NCLE O NAND Flash ROM Command Latch Enable
AP32 GCSB0 O GIO I/F Chip select
AP33 GCSB1 O GIO I/F Chip select (Not used)
AP34 VOID - This pin is not ball.
AP35 VOID - This pin is not ball.
AR1 VOID - This pin is not ball.
AR2 VOID - This pin is not ball.
AR3 VOID - This pin is not ball.
AR4 D1DQS3 I/O DDR2 Positive Data Strobe
AR5 GND - Ground for digital and DDR2 SDRAM
AR6 D1CLK1B O DDR2 Negative Clock
AR7 GND - Ground for digital and DDR2 SDRAM
AR8 D1DQS2 I/O DDR2 Positive Data Strobe
AR9 GND - Ground for digital and DDR2 SDRAM
AR10 VDD18 - 1.8V supply (DDR2 SDRAM)
AR11 D1DQ19 I/O DDR2 Data Input/Output
AR12 D1ODT0 O DDR2 On Die terminal control
AR13 D1ODT1 O DDR2 On Die terminal control
AR14 D1ADD11 O DDR2 Address Output
AR15 VDD18 - 1.8V supply (DDR2 SDRAM)
AR16 GND - Ground for digital and DDR2 SDRAM
AR17 D1ADD5 O DDR2 Address Output
AR18 D1BA0 O DDR2 Bank Address
AR19 D1DQ7 I/O DDR2 Data Input/Output
AR20 D1DQ5 I/O DDR2 Data Input/Output
AR21 VDD18 - 1.8V supply (DDR2 SDRAM)
AR22 GND - Ground for digital and DDR2 SDRAM
AR23 D1DQS0 I/O DDR2 Positive Data Strobe
AR24 GND - Ground for digital and DDR2 SDRAM
AR25 D1CLK0B O DDR2 Negative Clock
AR26 GND - Ground for digital and DDR2 SDRAM
AR27 D1DQS1 I/O DDR2 Positive Data Strobe
