7-6
BDP-BX2/S360
DriveMenu (Drive-related Diagnostics & Tools)
Overview:
This menu is used to operate the drive using drive-related diagnostics and tools.
Screen 1: Selecting items
Operations:
[UP] [DOWN] Move the cursor up or down
[ENT] Open the selected cursor item
[RET] Return to the top menu
> Test item list
1. Open/close the drive tray
2. Perform JT check
3. Write OP data to drive
4. Perform aging by opening and closing the drive tray
5. Perform device diagnostics for drive
6. Acquire and display LD time from drive
7. Check ӠIOP and display the results
Display Panel:
TrayOpen/Close: DV-O/C
JTCheck: DV-JT
RewriteOPData: DV-WOP
TrayAging: DV-AGN
DriveDeviceDiag: DV-DIAG
DriveLDTime: DV-LDTM
DeltaIOPCheck: DV-DIOP
- TrayOpen/Close (Screen 2)
Operations:
[UP][DOWN] Move the cursor up or down (Open/Close)
[ENT] Execute the selected cursor item
[RET] Return to the drive menu
- DriveDeviceDiag (Screen 3)
Operations:
[ENT] Execute DriveDeviceDiag
[RET] Return to the drive menu
- DriveLDTime (Screen 4)
Operations:
[ENT] Display the LD time of the drive
[RET] Return to the drive menu
- DeltaIOPCheck (Screen 5)
Operations:
[ENT] Display the 㼺IOP of the drive
[RET] Return to the drive menu
If 㼺IOP measurement is executed, version update by CD is no longer possible in Service Mode.
(Screen 1)
Diag
[1] TrayOpen/Close
[2] JTCheck
[3] RewriteOPData
[4] TrayAging
[5] DriveDeviceDiag
[6] DriveLDTime
[7] DeltaIOPCheck
Information is displayed here when one of the menu options
below is selected (See below.)
[1] TrayOpen/Close
[5] DriveDeviceDiag
[6] DriveLDTime
[7] DeltaIOPCheck
TrayCtrl
Open
Close
Processing…
DriveDeviceDiag
Remove DISC and close tray.
[ENT] Start Device Diag
OK - DeviceDiag
DriveLDTime
[ENT] Show LDTime
BD :[ 1:25]
DVD:[ 0:00]
CD :[ 0:00]
DeltaIOPCheck
[ENT] Start
BD :[ 0]
DVD:[ 2]
CD :[ 2]
TEMP:[ 0]
(Screen 2)TrayOpen/Close (Screen 3) DriveDeviceDiag
(Screen 4) DriveLDTime (Screen 5) DeltaIOPCheck
