7-5
BDP-BX2/S360
DiagMenu (Diagnostics: Video/Audio Tests)
Overview:
This menu is used to conduct the video test and audio test.
Screen 1: When the Video Test category is selected
[ENT] Show/Hide color bar
[UP][RET] Return to test category selection
Screen 2: When the Audio Test category is selected
[ENT] Play/stop audio tone
[UP][RET] Return to test category selection
>Video Test:
Color bars are output to all output pins.
>Audio Test
An audio tone is output to all output pins.
Display panel:
During Video Test: D-VIDEO
During Audio Test: D-AUDIO
(Screen 1)
Diag
Category: Video Test
HELP: [UP][ENT][RET]
(Screen 3)
Diag
Category: Audio Test
HELP: [UP][ENT][RET]
[ENT] Show Color Bar
[ENT] Generate TONE Sound
(Screen 2)
[ENT]
[ENT]
