7-4
BDP-BX2/S360
DiagMenu (Diagnostics: Device Test: Basic Model)
Overview:
This menu is used to conduct tests on devices installed on the board for the basic
model.
Screen 1: Selecting the test category
Operations:
[LEFT] [RIGHT] Select the category
[DOWN] [ENT] Open the selected category
Screen 2: Device test
After Device Test is selected in Screen 1, the device to be tested is selected.
Operations:
[LEFT] [RIGHT] Select the device to be tested
[ENT] Execute the test
[UP] Return to the test category selection
Move the cursor up
[DOWN] Move the cursor down
>Test category list
Device Test
Video Test
Audio Test
>Device Test: Device list
USB䇭Host
(1) :USB Media Check, Register Read Check
D/A Converter
(2) :DAC write check (non-verification)
Ifcon <- Check visually :IFCON-related test
1) No USB hub ID check in basic model
2) No 8[ch] D/A converter test in basic model
䇭For information about the device tests, refer to the diagnostics documentation.
Display panel:
When Category is selected: Device Test :D-DEV
Video Test :D-VIDEO
Audio Test :D-AUDIO
When Device is selected: USB Host :D-USB
D/A Converter :D-DAC
D Terminal :D-TERM
During USB Host Check: :USB CHK
All items are OK :USB OK
Some items are not OK :USB NG
During D/A Converter Check: :DAC CHK
All items are OK :DAC OK
Some items are not OK :DAC NG
(Screen 1)
Diag
Category:
(Screen 2)
Diag
Category: Device Test
Device:
USB Media check ... NG
Checking...
HELP: [RIGHT][UP][ENT][RET]
