(Screen 1)
Select Log
[2] Command Log
HELP : [DOWN][ENT][(NUM)]
Log: Command Log / Error Log (Display of Logs)
Overview:
This is used to display the log information.
Screen 1: Selecting the log type that is displayed
Operations:
[1] Open the Error Log output screen
[2] Open the Command Log output screen
[UP][DOWN] Move the cursor up or down
[ENT] Open the selected cursor item
[RET] Return to Service Mode top menu
Screen 2: Display of Error Log
Operations:
[LEFT] Previous page
[RIGHT] Next page
[RET] Return to screen for selecting log type (Screen 1)
[RED] Save the error log data to the USB memory device
Screen 3: Display of Command Log
Operations:
[LEFT] Previous page
[RIGHT] Next page
[RET] Return to screen for selecting log type (Screen 1)
[RED] Save the command log data to the USB memory device
Display panel:
When log type is selected Error log:䇭S-ELOG
Command log: S-CLOG
When log is displayed Page indicator䇭 ex) 1/50
>Reading the log display
Error log:䇭
001 08/01/01 00:53:19: [ErrCode:080400000000]
[Number (from oldest log)] [Date] [Time] [Error code]
Command log:
0001 08/01/01 00:53:19: 0 POWER 0
[No. (from oldest log)] [Date] [Time] [Count] [Command name] [Edge 0:on 1:off]
Copying logs to a USB memory device
Load the USB memory device into the set while the log screen is displayed, and press the [RED]
button.
Error log:
䇭䇭䇭䇭䇭䇭If the getErrLogFile.trm file is found in the USB memory device,
the errlog.log file is output.
Command log:
䇭䇭䇭䇭䇭䇭If the getCmdLogFile.trm file is found in the USB memory device,
the cmdlog.log file is output.
䃨This function cannot be used if USBHost test is being conducted in the Diag menu.
䇭䇭Several seconds are required for saving the data, and so be sure to wait long enough before
removing the USB memory device.
(Screen 2)
Error Log
001 08/01/01 00:53:19: [ErrCode:080400000000]
002 08/01/01 00:53:45: [ErrCode:080400252100]
003 08/01/01 00:54:00: [ErrCode:080400005555]
:
:
[1] Error Log
(Screen 3)
Command Log
0001 08/01/01 00:53:19: 0 POWER 0
0002 08/01/01 00:53:45: 1 POWER 1
0003 08/01/01 00:54:00: 79 OPEN_CLOSE 0
:
:
< Page 1/50 >
