6-15
DD-117
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CF-60/61
< DIODE >
D001 8-719-062-16 DIODE 01ZA8.2(TPL3)
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
D005 8-719-073-03 DIODE MA8082-(K8).S0
D006 8-719-073-03 DIODE MA8082-(K8).S0
D008 8-719-073-01 DIODE MA111-(K8).S0
D010 8-719-073-03 DIODE MA8082-(K8).S0
< IC >
IC001 8-759-573-02 IC BU9729K-E2
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
< TRANSISTOR >
Q001 8-729-402-42 TRANSISTOR UN5213-TX
(TR315E/TR415E/TR425E/TR515E/TR713E/TRV16E/TRV26E/TRV27E/
TRV27EP/TRV36E/TRV46E)
< RESISTOR >
R002 1-216-864-11 METAL CHIP 0 5% 1/16W
R005 1-216-833-11 METAL CHIP 10K 5% 1/16W
R006 1-216-833-11 METAL CHIP 10K 5% 1/16W
R007 1-216-833-11 METAL CHIP 10K 5% 1/16W
R008 1-216-833-11 METAL CHIP 10K 5% 1/16W
R009 1-216-833-11 METAL CHIP 10K 5% 1/16W
R011 1-216-855-11 METAL CHIP 680K 5% 1/16W
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
R012 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
R013 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R015 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R016 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R019 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R020 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R022 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R023 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R025 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R026 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R028 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
R029 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R031 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R032 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
R034 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
R035 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
R036 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R038 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R039 1-216-838-11 METAL CHIP 27K 5% 1/16W
R041 1-216-838-11 METAL CHIP 27K 5% 1/16W
R046 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
R047 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
R048 1-216-838-11 METAL CHIP 27K 5% 1/16W
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
R051 1-216-821-11 METAL CHIP 1K 5% 1/16W
R052 1-216-821-11 METAL CHIP 1K 5% 1/16W
< SWITCH >
S003 1-771-138-61 SWITCH, KEY BOARD (DATE)
S004 1-771-029-21 SWITCH, TACTILE (PROGRAM AE)
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
S006 1-771-138-61 SWITCH, KEY BOARD (PICTURE EFFECT)
S008 1-771-138-61 SWITCH, KEY BOARD (COUNTER RESET)
S010 1-771-029-21 SWITCH, TACTILE (MENU)
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
S010 1-771-138-61 SWITCH, KEY BOARD (MENU)
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
S012 1-771-029-21 SWITCH, TACTILE (EXPOSURE)
S013 1-771-138-61 SWITCH, KEY BOARD (END SEARCH)
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
S015 1-771-025-21 SWITCH, ROTARY (SELECT DIAL)(ENCODER)
S017 1-771-029-21 SWITCH, TACTILE (BACK LIGHT)
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
S017 1-771-138-61 SWITCH, KEY BOARD (BACK LIGHT)
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
S018 1-771-138-61 SWITCH, KEY BOARD (TITLE)
S020 1-762-442-21 SWITCH, ROTARY (AE DIAL)
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
S021 1-771-138-61 SWITCH, KEY BOARD (TIME)
S022 1-771-138-61 SWITCH, KEY BOARD (DISPLAY)
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
S024 1-762-648-21 SWITCH, SLIDE (START/STOP MODE)
A-7073-785-A DD-117(MMCB0) BOARD, COMPLETE (TR516E)
*****************************
A-7073-791-A DD-117(MMIB0) BOARD, COMPLETE (TR713E)
*****************************
A-7073-806-A DD-117(VMMIB0) BOARD, COMPLETE (TRV46E)
******************************
A-7073-818-A DD-117(ZL0) BOARD, COMPLETE
***************************
(TR315E/TR415E/TR425E)
A-7073-824-A DD-117(VZB0) BOARD, COMPLETE (TRV36E)
****************************
A-7073-830-A DD-117(ZB0) BOARD, COMPLETE (TR515E)
***************************
A-7073-874-A DD-117(VZL0) BOARD, COMPLETE
****************************
(TRV16E/TRV26E/TRV27E/TRV27EP)
(Ref. No. 2,000 Series)
< CAPACITOR >
C801 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C802 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C803 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C804 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C805 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C806 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C808 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C809 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C810 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C811 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
