Sony CCD-TR315E - Electrical Parts List

6-14
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
East European model is abbreviated as EE.
North European model is abbreviated as NE.
Russian model is abbreviated as RU.
Hong Kong model is abbreviated as HK.
Australian model is abbreviated as AUS.
Chinese model is abbreviated as CN.
Tourist model is abbreviated as JE.
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
6-2. ELECTRICAL PARTS LIST
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Be sure to read “Note on the CCD Imager replacement”
on page 4–9 when changing the CCD imager.
CD-210/211 CF-60/61
A-7073-786-A CD-210(NT) BOARD, COMPLETE
**************************
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
(Ref. No. 4,000 Series)
A-7073-807-A CD-211(NT) BOARD, COMPLETE
**************************
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
(Ref. No. 9,000 Series)
(IC401 is not including to the mounted board.)
< CAPACITOR >
C401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C405 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V
C406 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
< CONNECTOR >
CN401 1-766-346-21 CONNECTOR, FFC/FPC 16P
< IC >
IC401 A-7030-961-A CCD BLOCK ASSY (207 SERVICE)(CCD IMAGER)
(TR315E/TR415E/TR425E/TR515E/TR516E/TRV16E/TRV26E/TRV27E/
TRV27EP/TRV36E)
IC401 A-7030-962-A CCD BLOCK ASSY (243 SERVICE)(CCD IMAGER)
(TR713E/TRV46E)
< COIL >
L401 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q402 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R404 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R405 1-216-809-11 METAL CHIP 100 5% 1/16W
R406 1-216-864-11 METAL CHIP 0 5% 1/16W
A-7073-783-A CF-60(CN) BOARD, COMPLETE (TR516E)
*************************
A-7073-795-A CF-60(P) BOARD, COMPLETE
************************
(TR415E/TR425E/TR515E/TR713E)
A-7073-821-A CF-60(N) BOARD, COMPLETE (TR315E)
************************
(Ref. No. 4,000 Series)
A-7073-811-A CF-61 BOARD, COMPLETE
*********************
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
(Ref. No. 9,000 Series)
< BATTERY HOLDER >
BH001 1-550-104-11 HOLDER, BATTERY
< BUZZER >
BZ002 1-529-104-21 BUZZER, PIEZOELECTRIC
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
< CAPACITOR >
C003 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
< CONNECTOR >
CN001 1-774-054-21 CONNECTOR, FFC/FPC (ZIF) 45P
CN002 1-774-765-11 CONNECTOR, FFC/FPC 8P
* CN003 1-580-055-21 PIN, CONNECTOR (SMD) 2P
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
CN005 1-778-509-21 PIN, CONNECTOR (PC BOARD) 11P
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
CN006 1-778-508-21 PIN, CONNECTOR (PC BOARD) 6P
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
CN007 1-779-334-11 CONNECTOR, FFC/FPC 20P (TR516E)
* CN008 1-778-283-11 CONNECTOR, FFC/FPC 4P
(TR315E/TR415E/TR425E/TR515E/TR713E/TRV16E/TRV26E/TRV27E/
TRV27EP/TRV36E/TRV46E)
CN009 1-691-362-11 CONNECTOR, FFC/FPC (ZIF) 24P
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
