Sony CCD-TR315E - Page 162

6-19
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FP-249
FP-355 LB-54
R917 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
R918 1-216-849-11 METAL CHIP 220K 5% 1/16W
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
R921 1-216-296-91 SHORT 0
R922 1-216-296-91 SHORT 0
R923 1-216-296-91 SHORT 0
R924 1-216-849-11 METAL CHIP 220K 5% 1/16W
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
R925 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
R926 1-216-821-11 METAL CHIP 1K 5% 1/16W
R933 1-216-821-11 METAL CHIP 1K 5% 1/16W
R934 1-216-821-11 METAL CHIP 1K 5% 1/16W
R935 1-216-821-11 METAL CHIP 1K 5% 1/16W
R936 1-216-821-11 METAL CHIP 1K 5% 1/16W
R937 1-216-821-11 METAL CHIP 1K 5% 1/16W
R938 1-216-821-11 METAL CHIP 1K 5% 1/16W
R939 1-216-821-11 METAL CHIP 1K 5% 1/16W
R941 1-216-821-11 METAL CHIP 1K 5% 1/16W
R943 1-216-029-00 METAL CHIP 150 5% 1/10W
R944 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSFORMER >
! T801 1-429-565-21 TRANSFORMER, CONVERTER
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
! T801 1-431-749-21 TRANSFORMER, DC/DC CONVERTER
(TR315E/TR415E/TR425E/TR515E/TR516E/TR713E)
1-658-214-11 FP-249 FLEXIBLE BOARD
*********************
(Ref. No. 10,000 Series)
< HALL ELEMENT >
H001 8-719-033-37 ELEMENT, HALL HW-105C
H002 8-719-033-37 ELEMENT, HALL HW-105C
< TRANSISTOR >
Q001 8-729-907-25 PHOTO TRANSISTOR PT4850F
Q002 8-729-907-25 PHOTO TRANSISTOR PT4850F
< SWITCH >
S001 1-692-614-11 SWITCH, PUSH (3 KEY)
(Hi8 MP, ME/MP, REC PROOF)
S002 1-572-688-11 SWITCH, PUSH (1 KEY)(C.C. LOCK)
1-658-213-11 FP-355 FLEXIBLE BOARD
*********************
(Ref. No. 10,000 Series)
< DIODE >
D001 8-719-988-42 DIODE GL453
A-7073-439-A LB-54 BOARD, COMPLETE (TR516E)
*********************
(Ref. No. 10,000 Series)
< CAPACITOR >
C5351 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
C5352 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C5353 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5354 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C5355 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C5356 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
< CONNECTOR >
CN5351 1-784-564-11 CONNECTOR, BOARD TO BOARD 12P
< COIL >
L5351 1-412-031-11 INDUCTOR CHIP 47uH
L5352 1-412-029-11 INDUCTOR CHIP 10uH
< FLUORESCENT INDICATOR >
! ND5351 1-517-325-21 LAMP, FLUORESCENT (0.55 INCH)
< TRANSISTOR >
Q5351 8-729-039-24 TRANSISTOR FX216-TL1
< RESISTOR >
R5351 1-216-839-11 METAL CHIP 33K 5% 1/16W
< TRANSFORMER >
! T5351 1-426-849-41 TRANSFORMER, INVERTER
DD-117
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
