5-11
00 to 0F
10 00 Emergency memory address
11 00
12 00
13 00
14 00
15 00
16 00
17 00
18 00
19 00
1A 00
1B 00
1C Fixed data-2
1D
1E
1F
20
21 50 G-CAM flip adj.
22 Fixed data-2
23
24 Fixed data-1
25
26 Fixed data-2
27 Fixed data-1
28
29
2A
2B Fixed data-2
2C A0 28MHz origin osc. adj.
2D Fixed data-2
2E Fixed data-1
2F 80 Hall adj.
30 80
31 18 Max gain adj.
32 Fixed data-2
33 Fixed data-1
34 1B Color reproduction adj.
35 Fixed data-1
36 42 Color reproduction adj.
37 Fixed data-1
38
39
3A 89 Auto white balance adj.
3B 59
3C 38 IRIS IN/OUT adj.
3D 41
3E 25 Flange back adj.
3F 00
40 19
41 00
42 35
Address Initial Remark
Value
Address Initial Remark
Value
4. F Page table
Note 1:
Fixed data-1 : Initialized data.
( Refer to “1. Initializing the D,E,F Page Data”.)
Fixed data-2 : Modified data.
(Refer to “2. Modification of D, E, F Page Data”).
Note 2 :There are three models classified by VTR formats as shown
below, and the initial value of adjustment is different ac-
cording to the model.
Hi8 model :CCD-TR515E/TR516E/TR713E
CCD-TRV36E/TRV46E
Standard8 model : CCD-TR315E/TR415E/TR425E
CCD-TRV16E/TRV26E/TRV27E/TRV27EP
(
)
(
)
43 78 Angular velocity sensor sensitivity check.
44 6C Address 43, 44 are fixed data-2 address.
(CCD-TR713E/TRV46E)
45 Fixed data-1
46 8D 1.5MHz deviation adj.
47 7A BPF f0 adj.
48 Fixed data-1
49 6B Y OUT level adj.
4A 40 AFC f0 adj.
4B 9A C OUT level adj.
4C Fixed data-1
4D 7B Filter f0 adj.
4E 60 RP filter f0 adj.
4F Fixed data-1
50
51
52
53 40 REC Y current adj.
54 40 Addresses 57 to5A are fixed
55 40 data-2 addresses.
56 40
57 A1/80 Note 2 : Hi8 model/ Standard8 model
58 95/80
59 A1/80
5A 95/80
5B 50 REC L level adj.
5C 50 Addresses 63 to 64 are fixed
5D 50 data-2 addresses.
5E 50
5F 66
60 66
61 66
62 66
63 7A/80 Note 2 : Hi8 model/ Standard8 model
64 7A/80
65 80 REC C current adj.
66 41 IR video deviation Adj.
67 33 IR audio deviation Adj.
68 C7 IR video carrier freq. Adj.
69 80 CAP FG offset adj.
6A Fixed data-2
6B Fixed data-1
6C
6D
6E
6F
70 3B AWB standard data input adj.
71 FF
72 56
73 7D
74 Fixed data-1
75
76 1B Flange back adj.
77 54
78 25
79 80
7A 10
7B FF
7C 0A Switching position adj.
7D 00
7E Fixed data-1
7F
80 Fixed data-2
81
82 Fixed data-1
83
