SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
C514 1-136-810-11 FILM 220PF 5% 100V
C517 1-136-817-91 FILM 0.0033uF 5% 100V
C518 1-136-814-11 FILM 0.001uF 5% 100V
C519 1-104-646-11 CERAMIC 2.2uF 20% 50V
C520 1-117-775-31 FILM 0.1uF 10% 250V
C521 1-128-197-11 ELECT 10uF 20% 63V
C522 1-136-850-11 FILM 0.1uF 5% 63V
C523 1-136-850-11 FILM 0.1uF 5% 63V
C524 1-136-850-11 FILM 0.1uF 5% 63V
C525 1-136-850-11 FILM 0.1uF 5% 63V
C528 1-136-850-11 FILM 0.1uF 5% 63V
C529 1-136-850-11 FILM 0.1uF 5% 63V
C530 1-136-850-11 FILM 0.1uF 5% 63V
C531 1-130-973-00 FILM 0.022uF 3% 100V
C532 1-130-969-11 FILM 0.012uF 3% 100V
C533 1-130-969-11 FILM 0.012uF 3% 100V
C534 1-136-233-11 FILM 0.0047uF 3% 100V
C535 1-136-233-11 FILM 0.0047uF 3% 100V
C536 1-128-200-11 ELECT 47uF 20% 63V
C537 1-128-200-11 ELECT 47uF 20% 63V
C541 1-164-159-11 CERAMIC 0.1uF 50V
C551 1-162-199-31 CERAMIC 10PF 5% 50V
C552 1-126-024-11 ELECT 220uF 20% 25V
C553 1-162-199-31 CERAMIC 10PF 5% 50V
C601 1-126-023-11 ELECT 100uF 20% 25V
C602 1-164-732-11 CERAMIC 0.1uF 20% 50V
C603 1-164-159-11 CERAMIC 0.1uF 50V
C604 1-164-732-11 CERAMIC 0.1uF 20% 50V
C605 1-164-159-11 CERAMIC 0.1uF 50V
C606 1-164-732-11 CERAMIC 0.1uF 20% 50V
C607 1-162-290-31 CERAMIC 470PF 10% 50V
C608 1-128-200-11 ELECT 47uF 20% 63V
C609 1-117-775-31 FILM 0.1uF 10% 250V
C610 1-164-732-11 CERAMIC 0.1uF 20% 50V
C611 1-102-947-00 CERAMIC 10PF 5% 50V
C612 1-102-947-00 CERAMIC 10PF 5% 50V
C613 1-128-201-11 ELECT 100uF 20% 63V
C614 1-162-290-31 CERAMIC 470PF 10% 50V
C615 1-164-732-11 CERAMIC 0.1uF 20% 50V
C621 1-117-855-51 ELECT 10uF 20% 50V
C622 1-117-855-51 ELECT 10uF 20% 50V
C623 1-126-023-11 ELECT 100uF 20% 25V
C624 1-126-023-11 ELECT 100uF 20% 25V
C625 1-128-201-11 ELECT 100uF 20% 63V
* A-4699-569-A AUDIO BOARD, COMPLETE
**********************
< BUS BAR >
BB601 1-566-940-21 BUS BAR 3P
< CAPACITOR >
C401 1-136-850-11 FILM 0.1uF 5% 63V
C402 1-124-910-11 ELECT 47uF 20% 50V
C403 1-136-850-11 FILM 0.1uF 5% 63V
C404 1-124-910-11 ELECT 47uF 20% 50V
C405 1-136-850-11 FILM 0.1uF 5% 63V
C413 1-136-810-11 FILM 220PF 5% 100V
C414 1-136-810-11 FILM 220PF 5% 100V
C417 1-136-817-91 FILM 0.0033uF 5% 100V
C418 1-136-814-11 FILM 0.001uF 5% 100V
C419 1-104-646-11 CERAMIC 2.2uF 20% 50V
C420 1-117-775-31 FILM 0.1uF 10% 250V
C421 1-128-197-11 ELECT 10uF 20% 63V
C422 1-136-850-11 FILM 0.1uF 5% 63V
C423 1-136-850-11 FILM 0.1uF 5% 63V
C424 1-136-850-11 FILM 0.1uF 5% 63V
C425 1-136-850-11 FILM 0.1uF 5% 63V
C428 1-136-850-11 FILM 0.1uF 5% 63V
C429 1-136-850-11 FILM 0.1uF 5% 63V
C431 1-130-973-00 FILM 0.022uF 3% 100V
C432 1-130-969-11 FILM 0.012uF 3% 100V
C433 1-130-969-11 FILM 0.012uF 3% 100V
C434 1-136-233-11 FILM 0.0047uF 3% 100V
C435 1-136-233-11 FILM 0.0047uF 3% 100V
C436 1-128-200-11 ELECT 47uF 20% 63V
C437 1-128-200-11 ELECT 47uF 20% 63V
C441 1-164-159-11 CERAMIC 0.1uF 50V
C451 1-162-199-31 CERAMIC 10PF 5% 50V
C452 1-126-024-11 ELECT 220uF 20% 25V
C453 1-162-199-31 CERAMIC 10PF 5% 50V
C501 1-136-850-11 FILM 0.1uF 5% 63V
C502 1-124-910-11 ELECT 47uF 20% 50V
C503 1-136-850-11 FILM 0.1uF 5% 63V
C504 1-124-910-11 ELECT 47uF 20% 50V
C505 1-136-850-11 FILM 0.1uF 5% 63V
C513 1-136-810-11 FILM 220PF 5% 100V
AUDIO
When indicating parts by reference
number, please include the board.
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
To Next Page
