– 67 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C626 1-128-201-11 ELECT 100uF 20% 63V
C627 1-128-201-11 ELECT 100uF 20% 63V
C628 1-128-201-11 ELECT 100uF 20% 63V
C650 1-162-294-31 CERAMIC 0.001uF 10% 50V
C651 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN401 1-764-325-11 PIN, CONNECTOR (PCB) (V TYPE) 2P
CN402 1-764-325-11 PIN, CONNECTOR (PCB) (V TYPE) 2P
CN501 1-764-325-11 PIN, CONNECTOR (PCB) (V TYPE) 2P
CN502 1-764-325-11 PIN, CONNECTOR (PCB) (V TYPE) 2P
* CN601 1-691-462-11 PIN, CONNECTOR (PC BOARD) 6P
CN602 1-691-463-31 PIN, CONNECTOR (PC BOARD) 7P
CN608 1-764-326-11 PIN, CONNECTOR (PCB) (V TYPE) 3P
CN609 1-764-327-11 PIN, CONNECTOR (PCB) (V TYPE) 4P
CN610 1-764-327-11 PIN, CONNECTOR (PCB) (V TYPE) 4P
CN611 1-691-459-21 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D401 8-719-987-63 DIODE 1N4148M
D441 8-719-987-63 DIODE 1N4148M
D501 8-719-987-63 DIODE 1N4148M
D541 8-719-987-63 DIODE 1N4148M
D602 8-719-115-65 DIODE RD6.8JS-T2B1
D603 8-719-987-63 DIODE 1N4148M
D625 8-719-210-21 DIODE 11EQS04
D626 8-719-210-21 DIODE 11EQS04
< MOUNT/GROUND TERMINAL >
ET602 4-924-264-01 TERMINAL, MOUNT
ET650 1-537-770-21 TERMINAL BOARD, GROUND
ET651 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC401 8-759-259-12 IC OPA2604AP
IC402 8-759-443-33 IC OPA2132PA
IC403 8-759-053-07 IC OP-27GP
IC404 8-759-371-51 IC CXA8042AS
IC501 8-759-259-12 IC OPA2604AP
IC502 8-759-443-33 IC OPA2132PA
IC503 8-759-053-07 IC OP-27GP
IC504 8-759-371-51 IC CXA8042AS
IC601 8-759-462-70 IC CXD8679Q
IC602 8-759-242-70 IC TC7WU04F
IC603 8-759-454-42 IC CXD2562Q-CS
IC604 8-759-242-70 IC TC7WU04F
IC605 8-759-231-53 IC TA7805S
IC606 8-759-981-85 IC RC4556D
IC607 8-759-604-86 IC M5F7807L
IC608 8-759-604-90 IC M5F7907L
IC609 8-759-708-05 IC NJM78L05A
IC610 8-759-180-84 IC TC7W74F
< COIL >
L403 1-414-514-21 INDUCTOR 10uH
L404 1-414-512-21 INDUCTOR 6.8uH
L405 1-412-473-21 INDUCTOR 0uH
L406 1-412-473-21 INDUCTOR 0uH
L408 1-414-510-21 INDUCTOR 3.3uH
L441 1-414-512-21 INDUCTOR 6.8uH
L443 1-414-512-21 INDUCTOR 6.8uH
L451 1-414-512-21 INDUCTOR 6.8uH
L452 1-414-509-21 INDUCTOR 2.2uH
L453 1-414-512-21 INDUCTOR 6.8uH
L503 1-414-514-21 INDUCTOR 10uH
L504 1-414-512-21 INDUCTOR 6.8uH
L505 1-412-473-21 INDUCTOR 0uH
L506 1-412-473-21 INDUCTOR 0uH
L508 1-414-510-21 INDUCTOR 3.3uH
L541 1-414-512-21 INDUCTOR 6.8uH
L543 1-414-512-21 INDUCTOR 6.8uH
L551 1-414-512-21 INDUCTOR 6.8uH
L552 1-414-509-21 INDUCTOR 2.2uH
L553 1-414-512-21 INDUCTOR 6.8uH
L601 1-414-510-21 INDUCTOR 3.3uH
L602 1-414-510-21 INDUCTOR 3.3uH
L603 1-414-510-21 INDUCTOR 3.3uH
L605 1-414-510-21 INDUCTOR 3.3uH
< TRANSISTOR >
Q405 8-729-224-63 FET 2SK246-BL
Q441 8-729-900-80 TRANSISTOR DTC114ES
Q442 8-729-900-65 TRANSISTOR DTA144ES
Q451 8-729-231-55 TRANSISTOR 2SC2878-AB
Q505 8-729-224-63 FET 2SK246-BL
Q541 8-729-900-80 TRANSISTOR DTC114ES
Q542 8-729-900-65 TRANSISTOR DTA144ES
Q551 8-729-231-55 TRANSISTOR 2SC2878-AB
Q601 8-729-900-65 TRANSISTOR DTA144ES
Q607 8-729-900-65 TRANSISTOR DTA144ES
< RESISTOR >
R401 1-249-913-11 CARBON 390 1% 1/4W
R402 1-249-913-11 CARBON 390 1% 1/4W
R403 1-249-885-11 CARBON 27 1% 1/4W
R404 1-249-885-11 CARBON 27 1% 1/4W
R409 1-249-946-11 CARBON 9.1K 1% 1/4W
R410 1-249-946-11 CARBON 9.1K 1% 1/4W
R411 1-249-946-11 CARBON 9.1K 1% 1/4W
R412 1-249-946-11 CARBON 9.1K 1% 1/4W
R413 1-249-923-11 CARBON 1K 1% 1/4W
R414 1-249-923-11 CARBON 1K 1% 1/4W
R416 1-249-520-11 CARBON 47 5% 1/4W
R417 1-249-959-11 CARBON 33K 1% 1/4W
R418 1-249-931-11 CARBON 2.2K 1% 1/4W
R427 1-249-637-11 CARBON 33 5% 1/2W
R429 1-249-979-91 CARBON 220K 1% 1/4W
R430 1-249-995-11 CARBON 1M 5% 1/4W
R431 1-249-979-91 CARBON 220K 1% 1/4W
R432 1-249-977-11 CARBON 180K 1% 1/4W
R433 1-249-506-11 CARBON 12 5% 1/4W
R434 1-249-917-11 CARBON 560 1% 1/4W
R435 1-249-504-11 CARBON 10 5% 1/4W
R437 1-249-504-11 CARBON 10 5% 1/4W
R439 1-249-504-11 CARBON 10 5% 1/4W
R440 1-249-504-11 CARBON 10 5% 1/4W
R441 1-259-476-11 CARBON 100K 5% 1/6W
AUDIO
