– 68 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R442 1-259-452-11 CARBON 10K 5% 1/6W
R443 1-259-472-11 CARBON 68K 5% 1/6W
R451 1-259-444-11 CARBON 4.7K 5% 1/6W
R452 1-259-476-11 CARBON 100K 5% 1/6W
R453 1-259-456-11 CARBON 15K 5% 1/6W
R454 1-259-464-11 CARBON 33K 5% 1/6W
R455 1-259-468-11 CARBON 47K 5% 1/6W
R456 1-259-396-11 CARBON 47 5% 1/6W
R481 1-259-416-11 CARBON 330 5% 1/6W
R482 1-259-416-11 CARBON 330 5% 1/6W
R483 1-259-416-11 CARBON 330 5% 1/6W
R484 1-259-416-11 CARBON 330 5% 1/6W
R485 1-249-931-11 CARBON 2.2K 1% 1/4W
R491 1-259-440-11 CARBON 3.3K 5% 1/6W
R501 1-249-913-11 CARBON 390 1% 1/4W
R502 1-249-913-11 CARBON 390 1% 1/4W
R503 1-249-885-11 CARBON 27 1% 1/4W
R504 1-249-885-11 CARBON 27 1% 1/4W
R509 1-249-946-11 CARBON 9.1K 1% 1/4W
R510 1-249-946-11 CARBON 9.1K 1% 1/4W
R511 1-249-946-11 CARBON 9.1K 1% 1/4W
R512 1-249-946-11 CARBON 9.1K 1% 1/4W
R513 1-249-923-11 CARBON 1K 1% 1/4W
R514 1-249-923-11 CARBON 1K 1% 1/4W
R516 1-249-520-11 CARBON 47 5% 1/4W
R517 1-249-959-11 CARBON 33K 1% 1/4W
R518 1-249-931-11 CARBON 2.2K 1% 1/4W
R527 1-249-637-11 CARBON 33 5% 1/2W
R529 1-249-979-91 CARBON 220K 1% 1/4W
R530 1-249-995-11 CARBON 1M 5% 1/4W
R531 1-249-979-91 CARBON 220K 1% 1/4W
R532 1-249-977-11 CARBON 180K 1% 1/4W
R533 1-249-506-11 CARBON 12 5% 1/4W
R534 1-249-917-11 CARBON 560 1% 1/4W
R535 1-249-504-11 CARBON 10 5% 1/4W
R537 1-249-504-11 CARBON 10 5% 1/4W
R539 1-249-504-11 CARBON 10 5% 1/4W
R540 1-249-504-11 CARBON 10 5% 1/4W
R541 1-259-476-11 CARBON 100K 5% 1/6W
R542 1-259-452-11 CARBON 10K 5% 1/6W
R543 1-259-472-11 CARBON 68K 5% 1/6W
R551 1-259-444-11 CARBON 4.7K 5% 1/6W
R552 1-259-476-11 CARBON 100K 5% 1/6W
R553 1-259-456-11 CARBON 15K 5% 1/6W
R554 1-259-464-11 CARBON 33K 5% 1/6W
R555 1-259-468-11 CARBON 47K 5% 1/6W
R556 1-259-396-11 CARBON 47 5% 1/6W
R581 1-259-416-11 CARBON 330 5% 1/6W
R582 1-259-416-11 CARBON 330 5% 1/6W
R583 1-259-416-11 CARBON 330 5% 1/6W
R584 1-259-416-11 CARBON 330 5% 1/6W
R585 1-249-931-11 CARBON 2.2K 1% 1/4W
R591 1-259-440-11 CARBON 3.3K 5% 1/6W
R601 1-259-428-11 CARBON 1K 5% 1/6W
R602 1-259-428-11 CARBON 1K 5% 1/6W
R603 1-259-428-11 CARBON 1K 5% 1/6W
R604 1-259-428-11 CARBON 1K 5% 1/6W
R605 1-259-424-11 CARBON 680 5% 1/6W
R607 1-259-424-11 CARBON 680 5% 1/6W
R608 1-259-420-11 CARBON 470 5% 1/6W
R609 1-259-430-11 CARBON 1.2K 5% 1/6W
R610 1-259-420-11 CARBON 470 5% 1/6W
R611 1-259-420-11 CARBON 470 5% 1/6W
R612 1-249-947-11 CARBON 10K 1% 1/4W
R613 1-259-416-11 CARBON 330 5% 1/6W
R614 1-259-412-11 CARBON 220 5% 1/6W
R615 1-259-448-11 CARBON 6.8K 5% 1/6W
R616 1-259-420-11 CARBON 470 5% 1/6W
! R617 1-212-887-00 FUSIBLE 180 5% 1/4W F
R628 1-259-484-11 CARBON 220K 5% 1/6W
R629 1-259-460-11 CARBON 22K 5% 1/6W
R630 1-259-476-11 CARBON 100K 5% 1/6W
! R631 1-219-022-11 FUSIBLE 100 5% 1/2W F
! R632 1-219-022-11 FUSIBLE 100 5% 1/2W F
< VIBRATOR >
X601 1-577-685-11 FILTER, CRYSTAL (16MHz)
X602 1-579-161-11 VIBRATOR, CRYSTAL (45MHz)
************************************************************
* A-4699-545-A BSL BOARD, COMPLETE
*******************
< CONNECTOR >
CN11 1-580-864-11 SOCKET, CONNECTOR (SMT) 10P
< HOLE ELEMENT >
H11 8-719-987-62 DIODE LT140SAZ
H12 8-719-987-62 DIODE LT140SAZ
< RESISTOR/CHIP CONDUCTOR >
R11 1-216-049-91 METAL CHIP 1K 5% 1/10W
R12 1-216-049-91 METAL CHIP 1K 5% 1/10W
R13 1-216-295-91 CONDUCTOR, CHIP (2012)
R14 1-216-295-91 CONDUCTOR, CHIP (2012)
R15 1-216-295-91 CONDUCTOR, CHIP (2012)
************************************************************
* 1-663-631-11 COAX BOARD
***********
< CAPACITOR >
C702 1-104-645-11 CERAMIC 1uF 20% 50V
C703 1-164-732-11 CERAMIC 0.1uF 20% 50V
C704 1-136-165-00 FILM 0.1uF 5% 50V
C705 1-107-611-11 MICA 100PF 5% 500V
C706 1-164-732-11 CERAMIC 0.1uF 20% 50V
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
AUDIO BSL COAX
To Next Page
