Sony CDP-XA50ES - Page 49

– 69 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C707 1-126-023-11 ELECT 100uF 20% 25V
C708 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CN701 1-580-771-11 PIN, CONNECTOR (PC BOARD) 3P
CN703 1-580-771-31 PIN, CONNECTOR (PC BOARD) 3P
< IC >
IC702 8-759-242-70 IC TC7WU04F
< PIN JACK >
J701 1-507-567-71 JACK, PIN 1P (DIGITAL OUT COAXIAL)
< RESISTOR >
R701 1-259-401-11 CARBON 75 5% 1/6W
R702 1-259-412-11 CARBON 220 5% 1/6W
< COIL WITH CORE >
T701 1-459-795-11 COIL (WITH CORE)
************************************************************
* 1-654-256-11 DISPLAY BOARD
*************
* 4-969-510-01 HOLDER (FL)
< CAPACITOR >
C801 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C802 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C803 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C804 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C805 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C806 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C807 1-163-031-11 CERAMIC CHIP 0.01uF 50V
< FLUORECENT INDICATOR TUBE >
FLD801 1-517-357-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-759-324-36 IC LC7570E
IC802 8-759-324-36 IC LC7570E
IC803 8-759-324-36 IC LC7570E
IC804 8-749-923-80 IC GP1U90XB
< TRANSISTOR >
Q801 8-729-421-19 TRANSISTOR UN2213
Q802 8-729-424-18 TRANSISTOR UN2113-TX
< RESISTOR >
R801 1-216-029-00 METAL CHIP 150 5% 1/10W
R802 1-216-089-00 METAL CHIP 47K 5% 1/10W
R803 1-216-097-00 METAL CHIP 100K 5% 1/10W
************************************************************
* 1-653-906-11 FL RELAY BOARD
**************
< CONNECTOR >
CN291 1-568-794-11 SOCKET, CONNECTOR 12P
* CN292 1-568-950-11 PIN, CONNECTOR 12P
************************************************************
* 1-654-005-11 FLEX RELAY BOARD
****************
< CONNECTOR >
CN191 1-580-473-11 SOCKET, CONNECTOR 26P
CN192 1-580-460-11 SOCKET, CONNECTOR 26P
************************************************************
1-653-918-11 FLEXIBLE BOARD
**************
< SWITCH >
S21 1-571-958-11 SWITCH, PUSH (1 KEY) (LIMIT OUT)
S22 1-571-958-11 SWITCH, PUSH (1 KEY) (LIMIT IN)
************************************************************
* 1-663-628-11 FUSE BOARD
**********
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
! C991 1-113-924-11 CERAMIC 0.0047uF 20% 250V
! C992 1-113-924-11 CERAMIC 0.0047uF 20% 250V
! C993 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
* CN991 1-564-321-21 PIN, CONNECTOR 2P
CN992 1-770-128-11 PIN, CONNECTOR 2P
CN993 1-564-321-00 PIN, CONNECTOR 2P
CN994 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< FUSE >
! F991 1-532-279-00 FUSE, TIME-LAG (T0.5A/250V)
! F992 1-532-279-00 FUSE, TIME-LAG (T0.5A/250V)
< LINE FILTER >
! T991 1-421-915-11 COIL, LINE FILTER
************************************************************
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
FUSEFLEXIBLEFLEX RELAYFL RELAY
DISPLAY
COAX
