– 70 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* A-4699-345-A KEY-L BOARD, COMPLETE
*********************
< CONNECTOR >
CN850 1-580-774-11 PIN, CONNECTOR (PC BOARD) 6P
* CN851 1-580-772-11 PIN, CONNECTOR (PC BOARD) 4P
< RESISTOR >
R850 1-249-415-11 CARBON 680 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-419-11 CARBON 1.5K 5% 1/4W
R853 1-249-421-11 CARBON 2.2K 5% 1/4W
< SWITCH >
S850 1-554-303-21 SWITCH, TACTILE (ERASE)
S851 1-554-303-21 SWITCH, TACTILE (FILE)
S852 1-554-303-21 SWITCH, TACTILE (EDIT/TIME FADE)
S853 1-554-303-21 SWITCH, TACTILE (TIME)
S854 1-554-303-21 SWITCH, TACTILE (REPEAT)
S855 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
************************************************************
* A-4699-344-A KEY-R BOARD, COMPLETE
*********************
< CONNECTOR >
CN871 1-580-775-11 PIN, CONNECTOR (PC BOARD) 8P
CN872 1-580-770-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D871 8-719-303-02 LED SEL2510C-D (”)
D872 8-719-301-52 LED SEL2810A-C (P)
D873 8-719-046-41 LED SEL5521C-TP15 (FILTER)
< TRANSISTOR >
Q871 8-729-900-80 TRANSISTOR DTC114ES
Q872 8-729-900-80 TRANSISTOR DTC114ES
Q873 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R879 1-249-429-11 CARBON 10K 5% 1/4W
R880 1-249-429-11 CARBON 10K 5% 1/4W
R881 1-249-415-11 CARBON 680 5% 1/4W
R882 1-249-417-11 CARBON 1K 5% 1/4W
R883 1-249-419-11 CARBON 1.5K 5% 1/4W
R884 1-249-421-11 CARBON 2.2K 5% 1/4W
R885 1-247-843-11 CARBON 3.3K 5% 1/4W
R886 1-249-415-11 CARBON 680 5% 1/4W
R887 1-249-417-11 CARBON 1K 5% 1/4W
R888 1-249-419-11 CARBON 1.5K 5% 1/4W
R889 1-249-406-11 CARBON 120 5% 1/4W
R890 1-249-410-11 CARBON 270 5% 1/4W
R891 1-249-406-11 CARBON 120 5% 1/4W
< ROTARY ENCODER >
RV870 1-475-006-11 ENCODER, ROTARY
(≠ AMS ± PUSH ENTER)
< SWITCH >
S884 1-554-303-21 SWITCH, TACTILE (CHECK)
S885 1-554-303-21 SWITCH, TACTILE (CLEAR)
S886 1-554-303-21 SWITCH, TACTILE (FILTER)
S887 1-554-303-21 SWITCH, TACTILE (0)
S888 1-554-303-21 SWITCH, TACTILE ())
S889 1-554-303-21 SWITCH, TACTILE (§ OPEN/CLOSE)
S890 1-554-303-21 SWITCH, TACTILE (”)
S891 1-554-303-21 SWITCH, TACTILE (P)
S892 1-554-303-21 SWITCH, TACTILE (p)
************************************************************
* 1-663-629-11 LINE BOARD
**********
< CONNECTOR >
CN471 1-764-341-11 PIN, CONNECTOR (PCB) (L TYPE) 4P
CN472 1-764-341-31 PIN, CONNECTOR (PCB) (L TYPE) 4P
CN473 1-580-771-31 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D471 8-719-987-63 DIODE 1N4148M
< PIN JACK >
J471 1-568-101-11 JACK, PIN 4P (LINE OUT FIXED/VARIABLE)
< RESISTOR >
R470 1-249-637-11 CARBON 33 5% 1/2W
R471 1-249-528-91 CARBON 100 5% 1/4W
R570 1-249-637-11 CARBON 33 5% 1/2W
R571 1-249-528-91 CARBON 100 5% 1/4W
< RELAY >
RY471 1-515-804-11 RELAY
************************************************************
* 1-653-907-11 LOADING MOTOR BOARD
*********************
< CONNECTOR >
CN272 1-506-469-11 PIN, CONNECTOR 4P
************************************************************
* 1-653-905-11 LOADING SW BOARD
*****************
< CONNECTOR >
* CN281 1-568-942-11 PIN, CONNECTOR 4P
< RESISTOR >
R281 1-249-427-11 CARBON 6.8K 5% 1/4W
< SWITCH >
S281 1-692-193-11 SWITCH, PUSH (1 KEY) (IN)
S282 1-692-193-11 SWITCH, PUSH (1 KEY) (OUT)
S283 1-692-193-11 SWITCH, PUSH (1 KEY) (LD)
************************************************************
KEY-L KEY-R LINE LOADING MOTOR
LOADING SW
To Next Page
