67
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
DISC IN SW DISPLAY
* 1-676-709-11 DISC IN SW BOARD
****************
< SWITCH >
SW2 1-529-566-21 SWITCH, PUSH (1 KEY) (SELF)
SW3 1-529-566-21 SWITCH, PUSH (1 KEY) (DISC IN)
*************************************************************
* A-3294-884-A DISPLAY BOARD, COMPLETE (M750)
* A-3294-895-A DISPLAY BOARD, COMPLETE (M700R)
************************
1-694-685-11 CONDUCTIVE BOARD, CONNECTION
1-694-686-11 CONDUCTIVE BOARD, CONNECTION
1-694-687-11 CONDUCTIVE BOARD, CONNECTION
* 3-045-702-01 BRACKET (LCD) (MAIN)
* 3-045-703-01 PLATE (LCD) (MAIN),LIGHT GUIDE
* 3-045-704-01 SHEET (MAIN), DIFFUSION
* 3-045-705-01 SHEET (MAIN), REFLECTION
* 3-045-706-01 BRACKET (LCD) (SUB)
* 3-045-707-01 PLATE (LCD) SUB, LIGHT GUIDE
* 3-045-708-01 SHEET (SUB), DIFFUSION
< CAPACITOR >
C901 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C902 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C903 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C904 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C905 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C906 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C907 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C908 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C909 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C910 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C911 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C912 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C913 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN901 1-794-184-21 CONNECTOR, FPC 14P
< DIODE >
D902 8-719-422-41 DIODE MA8051-L-TX
D903 8-719-977-12 DIODE MA8068-M-TX
D904 8-719-977-12 DIODE MA8068-M-TX
D905 8-719-977-12 DIODE MA8068-M-TX
D906 8-719-977-12 DIODE MA8068-M-TX
D907 8-719-977-12 DIODE MA8068-M-TX
D908 8-719-420-14 DIODE MA8082-M(TX)
D909 8-719-422-80 DIODE MA8075-H-TX
D910 8-719-977-12 DIODE MA8068-M-TX
< IC >
IC901 8-759-653-26 IC LC75878W
IC902 8-759-653-26 IC LC75878W
IC903 8-749-012-25 IC RS-170-TU
< LIQUID CRYSTAL DISPLAY >
LCD901 1-803-913-11 DISPLAY PANEL, LIQUID CRYSTAL
LCD902 1-803-914-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED901 8-719-079-49 LED NSSW450-BRS-TVR (SONY)
LED903 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED904 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED905 8-719-079-26 LED NSSB440-WRST-THR (LCD BACK LIGHT)
LED906 8-719-079-26 LED NSSB440-WRST-THR (LCD BACK LIGHT)
LED907 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED908 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED911 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED912 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED913 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED914 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED915 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED916 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED917 8-719-078-39 LED CL-170SR-CD-T (RING ILLUMINATION)
LED918 8-719-078-39 LED CL-170SR-CD-T (RING ILLUMINATION)
LED919 8-719-078-39 LED CL-170SR-CD-T (RING ILLUMINATION)
LED920 8-719-078-39 LED CL-170SR-CD-T (RING ILLUMINATION)
LED921 8-719-078-39 LED CL-170SR-CD-T (MODE)
< SWITCH >
LSW901 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (TA)
(M700R)
LSW902 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (SOUND)
LSW903 1-771-883-11 SWITCH, TACTILE (WITH LED) (DSO)
LSW904 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (MENU)
LSW905 1-771-883-11 SWITCH, TACTILE (WITH LED) (DISC+)
LSW906 1-771-883-11 SWITCH, TACTILE (WITH LED) (. m)
LSW907 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (LIST)
LSW908 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (> M)
To Next Page
