CX-JT7
• PANEL BOARD IC202 BU2099FV (LED DRIVER, TAPE MECHANISM CONTROLLER)
Pin No. Pin Name I/O Description
1 VSS — Ground terminal
2NC—Not used
3 DATA I Serial data input from the LED driver
4 CLOCK I Serial data transfer clock signal input from the system controller
5 LCK I Serial data latch pulse clock signal input from the system controller
6CD1 O LED drive signal output of the DISC DIRECT PLAY 1 indicator “L”: LED on
7CD2 O LED drive signal output of the DISC DIRECT PLAY 2 indicator “L”: LED on
8CD3 O LED drive signal output of the DISC DIRECT PLAY 3 indicator “L”: LED on
9 I-BASS O LED drive signal output of the i-BASS indicator “L”: LED on
10 MOTOR O Capstan/reel motor drive signal output terminal “L”: motor on
11 A-SOL O Deck-A side trigger plunger drive signal output terminal “L”: plunger on
12 B-SOL O Deck-B side trigger plunger drive signal output terminal “L”: plunger on
13 to 17 NC — Not used
18 SO O Serial data output to the multi controller
19 OE — Not used
20 VDD — Power supply terminal (+3.3V)
To Next Page
