Sony CX-JT7 - Page 75

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
75
CX-JT7
BD CD BUTTON
FB806 1-550-907-21 FERRITE 0uH
FB807 1-550-907-21 FERRITE 0uH
FB808 1-550-907-21 FERRITE 0uH
< IC >
IC721 6-701-796-01 IC LC78646E-E
IC722 6-704-220-01 IC BA5836FP
IC801 6-704-008-01 IC LC78684E-E
IC802 6-704-009-01 IC LC32V4265CT-25-MPB-E
IC803 6-704-007-01 IC MM1571J
< TRANSISTOR >
Q701 8-729-054-51 TRANSISTOR UP04116008S0
< RESISTOR >
R701 1-216-841-11 METAL CHIP 47K 5% 1/10W
R702 1-216-835-11 METAL CHIP 15K 5% 1/10W
R703 1-216-835-11 METAL CHIP 15K 5% 1/10W
R704 1-216-835-11 METAL CHIP 15K 5% 1/10W
R705 1-216-835-11 METAL CHIP 15K 5% 1/10W
R706 1-216-841-11 METAL CHIP 47K 5% 1/10W
R707 1-216-797-11 METAL CHIP 10 5% 1/10W
R708 1-216-833-11 METAL CHIP 10K 5% 1/10W
R709 1-216-838-11 METAL CHIP 27K 5% 1/10W
R711 1-216-815-11 METAL CHIP 330 5% 1/10W
R713 1-216-821-11 METAL CHIP 1K 5% 1/10W
R714 1-216-809-11 METAL CHIP 100 5% 1/10W
R715 1-216-809-11 METAL CHIP 100 5% 1/10W
R716 1-216-809-11 METAL CHIP 100 5% 1/10W
R717 1-216-809-11 METAL CHIP 100 5% 1/10W
R718 1-216-809-11 METAL CHIP 100 5% 1/10W
R719 1-216-809-11 METAL CHIP 100 5% 1/10W
R720 1-216-809-11 METAL CHIP 100 5% 1/10W
R721 1-216-809-11 METAL CHIP 100 5% 1/10W
R722 1-216-821-11 METAL CHIP 1K 5% 1/10W
R725 1-216-819-11 METAL CHIP 680 5% 1/10W
R726 1-216-819-11 METAL CHIP 680 5% 1/10W
R727 1-216-809-11 METAL CHIP 100 5% 1/10W
R728 1-216-841-11 METAL CHIP 47K 5% 1/10W
R729 1-216-834-11 METAL CHIP 12K 5% 1/10W
R730 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R731 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R732 1-216-864-11 SHORT CHIP 0
R738 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R739 1-216-864-11 SHORT CHIP 0
R740 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R741 1-216-864-11 SHORT CHIP 0
R744 1-216-845-11 METAL CHIP 100K 5% 1/10W
R745 1-216-809-11 METAL CHIP 100 5% 1/10W
R746 1-216-803-11 METAL CHIP 33 5% 1/10W
R747 1-216-803-11 METAL CHIP 33 5% 1/10W
R760 1-216-809-11 METAL CHIP 100 5% 1/10W
R765 1-216-857-11 METAL CHIP 1M 5% 1/10W
R801 1-216-809-11 METAL CHIP 100 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R803 1-216-809-11 METAL CHIP 100 5% 1/10W
R804 1-216-809-11 METAL CHIP 100 5% 1/10W
R805 1-216-809-11 METAL CHIP 100 5% 1/10W
R806 1-216-809-11 METAL CHIP 100 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R817 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R818 1-216-811-11 METAL CHIP 150 5% 1/10W
R819 1-216-821-11 METAL CHIP 1K 5% 1/10W
R820 1-216-821-11 METAL CHIP 1K 5% 1/10W
R823 1-216-809-11 METAL CHIP 100 5% 1/10W
R824 1-216-809-11 METAL CHIP 100 5% 1/10W
R825 1-216-809-11 METAL CHIP 100 5% 1/10W
R826 1-216-809-11 METAL CHIP 100 5% 1/10W
R827 1-216-809-11 METAL CHIP 100 5% 1/10W
R828 1-216-809-11 METAL CHIP 100 5% 1/10W
R829 1-216-809-11 METAL CHIP 100 5% 1/10W
R832 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R833 1-216-809-11 METAL CHIP 100 5% 1/10W
R834 1-216-809-11 METAL CHIP 100 5% 1/10W
R860 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S701 1-771-853-11 SWITCH, DETECTION (LIMIT IN)
< VIBRATOR >
X701 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
1-688-546-11 CD BUTTON BOARD
****************
< CONNECTOR >
CN302 1-568-850-11 CONNECTOR, FFC 7P
< LED >
LED301 8-719-063-93 LED SLR325VC-N-T32(DISC DIRECT PLAY 1)
LED302 8-719-063-93 LED SLR325VC-N-T32(DISC DIRECT PLAY 2)
LED303 8-719-063-93 LED SLR325VC-N-T32(DISC DIRECT PLAY 3)
< RESISTOR >
R327 1-247-843-11 CARBON 3.3K 5% 1/4W
R328 1-249-425-11 CARBON 4.7K 5% 1/4W
R329 1-249-427-11 CARBON 6.8K 5% 1/4W
R330 1-249-429-11 CARBON 10K 5% 1/4W
R331 1-249-429-11 CARBON 10K 5% 1/4W
R332 1-249-417-11 CARBON 1K 5% 1/4W
R341 1-249-417-11 CARBON 1K 5% 1/4W
R342 1-249-417-11 CARBON 1K 5% 1/4W
< SWITCH >
S327 1-762-875-21 SWITCH, KEYBOARD
(DISC CHANGE/DISC SKIP)
S328 1-762-875-21 SWITCH, KEYBOARD (DISC DIRECT PLAY 1)
S329 1-762-875-21 SWITCH, KEYBOARD (DISC DIRECT PLAY 2)
S330 1-762-875-21 SWITCH, KEYBOARD (DISC DIRECT PLAY 3)
S331 1-762-875-21 SWITCH, KEYBOARD (Z OPEN/CLOSE)
**************************************************************
