76
CX-JT7
1-687-135-11 DRIVER BOARD
*************
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-21 CERAMIC 0.1uF 50V
C736 1-164-159-21 CERAMIC 0.1uF 50V
C737 1-164-159-21 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 30% 16V
C751 1-162-306-11 CERAMIC 0.01uF 30% 16V
C752 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-785-338-11 PIN, CONNECTOR (LIGHT ANGLE) 12P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P
< DIODE >
D701 8-719-921-42 DIODE MTZJ-5.1A
D711 8-719-109-69 DIODE RD3.6ES-B2
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-417-11 CARBON 1K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W
R713 1-249-433-11 CARBON 22K 5% 1/4W
R721 1-249-425-11 CARBON 4.7K 5% 1/4W
R722 1-249-425-11 CARBON 4.7K 5% 1/4W
R723 1-249-425-11 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-249-417-11 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R735 1-247-807-31 CARBON 100 5% 1/4W
R751 1-249-425-11 CARBON 4.7K 5% 1/4W
**************************************************************
1-688-545-11 HEADPHONE BOARD
*****************
< CAPACITOR >
C301 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C302 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
< JACK >
J221 1-793-829-11 JACK, HEADPHONE (PHONES)
**************************************************************
A-4734-189-A MAIN BOARD, COMPLETE (AEP, UK)
A-4734-797-A MAIN BOARD, COMPLETE (CIS)
A-4738-393-A MAIN BOARD, COMPLETE (MX, E51)
*********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C101 1-126-963-11 ELECT 4.7uF 20% 50V
C102 1-126-963-11 ELECT 4.7uF 20% 50V
C103 1-126-933-11 ELECT 100uF 20% 16V
C108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(AEP, UK, CIS)
C201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C221 1-126-947-11 ELECT 47uF 20% 16V
C223 1-130-973-00 MYLAR 0.022uF 5% 100V
C225 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C226 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C232 1-126-947-11 ELECT 47uF 20% 16V
C233 1-130-471-00 MYLAR 0.001uF 5% 50V
C234 1-130-471-00 MYLAR 0.001uF 5% 50V
C237 1-126-960-11 ELECT 1uF 20% 50V
C239 1-130-485-00 MYLAR 0.015uF 5% 50V
C240 1-126-964-11 ELECT 10uF 20% 50V
C241 1-130-479-00 MYLAR 0.0047uF 5% 50V
C242 1-130-479-00 MYLAR 0.0047uF 5% 50V
C244 1-126-947-11 ELECT 47uF 20% 16V
C247 1-126-961-11 ELECT 2.2uF 20% 50V
C248 1-126-961-11 ELECT 2.2uF 20% 50V
C249 1-126-961-11 ELECT 2.2uF 20% 50V
C250 1-126-961-11 ELECT 2.2uF 20% 50V
C253 1-126-933-11 ELECT 100uF 20% 16V
C254 1-126-963-11 ELECT 4.7uF 20% 50V
C258 1-126-963-11 ELECT 4.7uF 20% 50V
C259 1-128-551-11 ELECT 22uF 20% 25V
C260 1-126-959-11 ELECT 0.47uF 20% 50V
C261 1-126-959-11 ELECT 0.47uF 20% 50V
C266 1-130-483-00 MYLAR 0.01uF 5% 50V
C267 1-130-483-00 MYLAR 0.01uF 5% 50V
C268 1-126-960-11 ELECT 1uF 20% 50V
C269 1-126-960-11 ELECT 1uF 20% 50V
C272 1-126-960-11 ELECT 1uF 20% 50V
C273 1-126-960-11 ELECT 1uF 20% 50V
C285 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C286 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C300 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-126-964-11 ELECT 10uF 20% 50V
C302 1-126-964-11 ELECT 10uF 20% 50V
C303 1-104-665-11 ELECT 100uF 20% 10V
C304 1-126-963-11 ELECT 4.7uF 20% 50V
C309 1-126-964-11 ELECT 10uF 20% 50V
C310 1-126-964-11 ELECT 10uF 20% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-964-11 ELECT 10uF 20% 50V
C313 1-107-714-11 ELECT 10uF 20% 16V
C314 1-107-714-11 ELECT 10uF 20% 16V
DRIVER HEADPHONE MAIN
