Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
80
CX-JT7
R375 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP, UK, CIS)
R378 1-216-833-11 METAL CHIP 10K 5% 1/10W
R379 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R380 1-216-853-11 METAL CHIP 470K 5% 1/10W
R384 1-216-821-11 METAL CHIP 1K 5% 1/10W
R386 1-216-833-11 METAL CHIP 10K 5% 1/10W
R387 1-216-834-11 METAL CHIP 12K 5% 1/10W
R388 1-216-821-11 METAL CHIP 1K 5% 1/10W
R390 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SUFFIX-13)
R391 1-216-841-11 METAL CHIP 47K 5% 1/10W
R392 1-216-813-11 METAL CHIP 220 5% 1/10W
R393 1-216-833-11 METAL CHIP 10K 5% 1/10W
R394 1-216-001-00 RES-CHIP 10 5% 1/10W
R395 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R396 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R397 1-216-821-11 METAL CHIP 1K 5% 1/10W
R398 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(MX, E51)
R398 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP, UK, CIS)
R399 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(MX, E51)
R399 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP, UK, CIS)
R400 1-216-833-11 METAL CHIP 10K 5% 1/10W
R401 1-216-833-11 METAL CHIP 10K 5% 1/10W
R402 1-216-833-11 METAL CHIP 10K 5% 1/10W
R403 1-216-820-11 METAL CHIP 820 5% 1/10W
(MX, E51)
R403 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(AEP, UK, CIS)
R404 1-216-833-11 METAL CHIP 10K 5% 1/10W
R405 1-216-833-11 METAL CHIP 10K 5% 1/10W
R406 1-216-837-11 METAL CHIP 22K 5% 1/10W
R407 1-216-833-11 METAL CHIP 10K 5% 1/10W
R408 1-216-833-11 METAL CHIP 10K 5% 1/10W
R409 1-216-833-11 METAL CHIP 10K 5% 1/10W
R410 1-216-833-11 METAL CHIP 10K 5% 1/10W
R412 1-216-833-11 METAL CHIP 10K 5% 1/10W
R413 1-216-833-11 METAL CHIP 10K 5% 1/10W
R414 1-216-833-11 METAL CHIP 10K 5% 1/10W
R415 1-216-833-11 METAL CHIP 10K 5% 1/10W
R416 1-216-833-11 METAL CHIP 10K 5% 1/10W
R417 1-216-833-11 METAL CHIP 10K 5% 1/10W
R418 1-216-833-11 METAL CHIP 10K 5% 1/10W
R419 1-216-833-11 METAL CHIP 10K 5% 1/10W
R421 1-216-833-11 METAL CHIP 10K 5% 1/10W
R424 1-216-837-11 METAL CHIP 22K 5% 1/10W
R425 1-216-837-11 METAL CHIP 22K 5% 1/10W
R426 1-216-837-11 METAL CHIP 22K 5% 1/10W
R427 1-216-296-11 SHORT CHIP 0
R428 1-216-296-11 SHORT CHIP 0
R430 1-216-833-11 METAL CHIP 10K 5% 1/10W
R431 1-216-847-11 METAL CHIP 150K 5% 1/10W
R432 1-216-809-11 METAL CHIP 100 5% 1/10W
0R433 1-215-891-11 METAL OXIDE 680 5% 2W F
0 R434 1-215-891-11 METAL OXIDE 680 5% 2W F
R455 1-218-717-11 METAL CHIP 11K 5% 1/10W
R460 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R461 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R466 1-216-837-11 METAL CHIP 22K 5% 1/10W
R467 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R468 1-216-844-11 METAL CHIP 82K 5% 1/10W
R470 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R478 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(MX, E51)
R479 1-216-841-11 METAL CHIP 47K 5% 1/10W
R480 1-216-833-11 METAL CHIP 10K 5% 1/10W
R481 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R482 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R483 1-216-821-11 METAL CHIP 1K 5% 1/10W
R484 1-216-833-11 METAL CHIP 10K 5% 1/10W
R485 1-216-809-11 METAL CHIP 100 5% 1/10W
R486 1-216-809-11 METAL CHIP 100 5% 1/10W
R487 1-216-296-11 SHORT CHIP 0
R488 1-216-296-11 SHORT CHIP 0
R491 1-216-849-11 METAL CHIP 220K 5% 1/10W
R492 1-216-849-11 METAL CHIP 220K 5% 1/10W
R493 1-216-845-11 METAL CHIP 100K 5% 1/10W
R494 1-216-849-11 METAL CHIP 220K 5% 1/10W
R495 1-216-837-11 METAL CHIP 22K 5% 1/10W
R498 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SUFFIX-13)
R499 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SUFFIX-13)
**************************************************************
1-688-547-11 MICROPHONE BOARD (MX, E51)
******************
< CONNECTOR >
* CN402 1-695-326-31 PIN, CONNECTOR (PC BOARD) 3P
< JACK >
J401 1-770-226-11 JACK (LARGE TYPE) (MIC)
**************************************************************
1-687-133-11 MOTOR (LD) BOARD
****************
**************************************************************
1-687-134-11 MOTOR (TB) BOARD
*****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
**************************************************************
MAIN MICROPHONE MOTOR (LD) MOTOR (TB)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
