Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
81
CX-JT7
A-4734-180-A PANEL BOARD, COMPLETE (AEP, UK)
A-4734-284-A PANEL BOARD, COMPLETE (MX, E51)
A-4734-792-A PANEL BOARD, COMPLETE (CIS)
**********************
4-245-151-01 GUIDE, FL
< CAPACITOR >
C201 1-126-960-11 ELECT 1uF 20% 50V
C202 1-164-173-11 CERAMIC CHIP 0.0039uF 10% 50V
C203 1-126-965-11 ELECT 22uF 20% 50V
C204 1-164-345-11 CERAMIC CHIP 0.082uF 10% 25V
C205 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C207 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C208 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C210 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C211 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C214 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C215 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C216 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C217 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C218 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C219 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C221 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(MX, E51)
C402 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(MX, E51)
C403 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(MX, E51)
C404 1-126-961-11 ELECT 2.2uF 20% 50V
(MX, E51)
C405 1-126-964-11 ELECT 10uF 20% 50V
(MX, E51)
C406 1-126-934-11 ELECT 220uF 20% 10V
(MX, E51)
C407 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
(MX, E51)
C408 1-126-956-11 ELECT 0.1uF 20% 50V
(MX, E51)
C409 1-126-964-11 ELECT 10uF 20% 50V
(MX, E51)
C410 1-126-965-11 ELECT 22uF 20% 50V
(MX, E51)
C411 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(MX, E51)
C412 1-126-960-11 ELECT 1uF 20% 50V
(MX, E51)
C413 1-126-960-11 ELECT 1uF 20% 50V
(MX, E51)
C414 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(MX, E51)
C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(MX, E51)
C434 1-126-957-11 ELECT 0.22uF 20% 50V
(MX, E51)
C441 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(MX, E51)
C501 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C502 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C504 1-126-964-11 ELECT 10uF 20% 50V
C505 1-126-916-11 ELECT 1000uF 20% 6.3V
C506 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C507 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C509 1-124-248-00 ELECT 22uF 20% 35V
C510 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C511 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C513 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C801 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C802 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C803 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C804 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C805 1-128-821-11 CERAMIC 1000PF 5% 50V
C806 1-128-821-11 CERAMIC 1000PF 5% 50V
C807 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C808 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C809 1-124-589-11 ELECT 47uF 20% 16V
C914 1-119-772-11 ELECT 47uF 20% 35V
C915 1-127-880-11 CERAMIC 0.022uF 10% 50V
C916 1-126-963-11 ELECT 4.7uF 20% 50V
C917 1-126-963-11 ELECT 4.7uF 20% 50V
C918 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C919 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C920 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C921 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C922 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C923 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C926 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C927 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C931 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C932 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C933 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
< CONNECTOR >
CN101 1-784-792-11 CONNECTOR, FFC 31P
CN301 1-568-826-11 CONNECTOR, FFC 7P
* CN401 1-695-326-31 PIN, CONNECTOR (PC BOARD) 3P (MX, E51)
CN601 1-784-774-11 CONNECTOR, FFC 13P
CN701 1-568-828-11 CONNECTOR, FFC 9P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D201 8-719-991-33 DIODE 1SS133T-77
D401 8-719-991-33 DIODE 1SS133T-77 (MX, E51)
D402 8-719-991-33 DIODE 1SS133T-77 (MX, E51)
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D503 8-719-991-33 DIODE 1SS133T-77
D504 8-719-991-33 DIODE 1SS133T-77
D505 8-719-991-33 DIODE 1SS133T-77
D506 8-719-991-33 DIODE 1SS133T-77
D510 8-719-991-33 DIODE 1SS133T-77
D511 8-719-991-33 DIODE 1SS133T-77
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-991-33 DIODE 1SS133T-77
D603 8-719-820-05 DIODE 1SS181
D604 8-719-820-05 DIODE 1SS181
D605 8-719-820-05 DIODE 1SS181
PANEL
