DCR-HC39E/HC41/HC42/HC42E/HC43/HC43E
4-3. SERVICE MODE
Note: Before performing the adjustment, check the data of page:
0, address: 10 is “00”. If not, select page: 0, address: 00,
and set data “00”.
1. Setting the Test Mode
Page A Address 10
Data Function
00 Normal
01 Forced camera power ON (CAMERA-TAPE mode)
02 Forced VTR power ON (PLAY/EDIT mode)
03 Forced camera + VTR power ON
05
Forced memory power ON
(CAMERA-MEMORY mode)
• Before setting the data , select page: 0, address: 01, and set data:
01.
•For page A, the data set will be recorded in the non-volatile
memory by pressing the PAUSE button of the adjustment re-
mote commander. In this case, take note that the test mode will
not be exited even when the main power is turned off (8.4 Vdc).
• After completing adjustments/repairs, be sure to return the data
of this address to 00, and press the PAUSE button of the adjust-
ment remote commander. And select page: 0, address: 01, and
set data: 00.
2. Emergence Memory Address
2-1. Emergency Memory Address (Camera section)
Page 19 Address 87 to 8A
Note: If reading/writing data on pages 19, set data: 01 to page:
0, address: 10, and then select pages: 9. By this data set-
ting, the pages 19 can be selected.
After the data reading/writing finished, return the data on
page: 0, address: 10 to “00”.
Address Contents
87 EMG code when first error occurs
88 EMG code when second error occurs
89 EMG code when third error occurs
8A EMG code when last error occurs
When no error occurs in this unit, data “00” is written in the above
addresses (87 to 8A). when first error occurs in the unit, the data
corresponding to the error is written in the first emergency ad-
dress (87). In the same way, when the second error occurs, the
data corresponding to the error is written in the second emergency
address (88).
Finally, when the last error occurs, the data corresponding to the
error is written in the last emergency address (8A).
Note: After completing adjustments, be sure to initialize the data
of addresses 87 to 8A to “00”.
Initializing method:
Order Page Address Data Procedure
10 0101
26 01 FD Press PAUSE button.
36 02
Check the data changes to
“01”.
46 01 00 Press PAUSE button.
50 0100
2-2. EMG Code (Emergency Code)
Codes corresponding to the errors which occur are written in 19
page, addresses 87 to 8A. The type of error indicated by the code
are shown in the following table.
Code Emergency Type
00 No error
