DCR-HC39E/HC41/HC42/HC42E/HC43/HC43E
4-79
FP-826, FP-467, FP-228
4-80
1
27
1
8
1
8
S902
MODE SWITCH
M902
LOADING
MOTOR
D901
(TAPE LED)
S903
(CC DOWN)
(REC PROOF)
4 PIN
CONNECTOR
MIC902
Q901
TAPE END
SENSOR
FP-826 FLEXIBLE BOARD
FP-467 FLEXIBLE BOARD
1-677-049-
1-861-117-
1-686-798-
11
12 22
11
DEW
SENSOR
FP-228
FLEXIBLE
BOARD
H902
T REEL
SENSOR
H901
S REEL
SENSOR
Q902
TAPE TOP
SENSOR
M
: Uses unleaded solder.
FP-826, FP-467, FP-228
Note for Printed Wiring Board (See page 4-63).
