Sony DXC-9100P - Specifications; Video System

59
Specifications
Image system/optical system
Pickup device1/2-inch CCD, interline transfer type
Effective picture elements
782 (horizontal) × 582 (vertical)
Lens mount 1/2-inch bayonet type
Video system
Synchronization
Internal/external (VBS, BS, SYNC, HD/VD)
synchronization, automatic switching
Signal format
PAL standard format
Scanning
625 lines, 2:1 interlace
Scanning frequency
Horizontal: 15.625 kHz
Vertical:50 Hz
N.I format
Scanning
760 × 575, 1/50, non-interlace
Scanning frequency
Horizontal: 31.25 kHz
Vertical: 50 Hz
Functions/performance
Horizontal resolution
Horizontal: 800 TV lines
Vertical: 575 TV lines
Sensitivity 2,000 lux (F5.6, 3200K)
Signal-to-noise ratio
57 dB
Gain control AGC and 0 to 18 dB in units of 1 dB
White balancing
Automatic
Manual: Red gain and green gain adjustable
individually
ATW
Electronic shutter speed
Step mode: Adjustable in range of 1/10,000
to about 8.0 seconds
Variable mode: Adjustable range of 1 to 255
frame and 312/625H to 1/625H (Usable
with CCD IRIS)
External trigger shutter
On/off switchable
Gamma compensation
On/off switchable
Color temperature
3200K/5600K
Freeze control
Switchable between INT. CTRL and EXT.
CTRL
