XBR-49/55/65/75X900E
DISASSEMBLY
1-37. WIRE DRESSING AND SHIELD, LD (L SBT)
1. XBR-55X900E
100
1 2
3 4 5
4 screws (SCREW, +PSW M3X6) P/N: 4-472-518-11
SHIELD, LD (L SBT)
