XBR-49/55/65/75X900E
WIRE DRESSING
*This page is only the information which shows each rough location.
60
XBR-49X900E
XBR-65X900E
Slide Clamp x1
• Hold wires
Harness Tie x4
• Fix wire
VA Tape x18
・Fix wire
Slide Clamp x2
• Hold wires
Harness Tie x5
• Fix wire
VA Tape x19
・Fix wire
XBR-75X900E
Slide Clamp x1
• Hold wires
Harness Tie x5
• Fix wire
VA Tape x21
・Fix wire
XBR-55X900E
Slide Clamp x2
• Hold wires
Harness Tie x5
• Fix wire
VA Tape x20
・Fix wire
