XBR-49/55/65/75X900E
DISASSEMBLY
2-17. TSA2 AND BRACKET, TS (PUC)
2. XBR-65X900E
117
1
3
2
4 5 6
Screw (SCREW, +PSW M3X6) P/N: 4-472-518-11
TSA2
BRACKET, TS (PUC)
