XBR-49/55/65/75X900E
DISASSEMBLY
1-25. BRACKET, IR IN AND IR (UC2 ONLY)
1. XBR-55X900E
87
1
2 3 4
Screw (SCREW, +PSW M3X6) P/N: 4-472-518-11
