XBR-49/55/65/75X900E
DISASSEMBLY
2-15. SWITCH UNIT (3M-P) AND HOLDER SIDE SW (PDT)
2. XBR-65X900E
115
1 2 3
4 5 7 6
SWITCH UNIT (3M-P)
Screw (SCREW M3X3.0 STEP) P/N: 4-579-926-01
HOLDER SIDE SW (PDT)
